Engineered for critical machinery protection systems, the 330102-00-19-15-11-05 represents a robust eddy current sensor from the Bently Nevada 3300 XL 8 mm series. This proximity probe measures static (position) and dynamic (vibration) parameters on rotating shafts, providing vital data for turbine supervisory instrumentation (TSI) and asset condition monitoring.
This specific configuration features a 3/8-24 UNF threaded case wrapped in a flexible stainless steel armor sleeve to defend against mechanical wear and debris. With a 1.5-meter (4.9-foot) overall length, the sensor utilizes FluidLoc cable technology to prevent process fluids from migrating through the internal cable structure, while the miniature coaxial ClickLoc connector ensures a highly stable electrical interface with the system's extension cable and proximitor sensor.
| Manufacturer | Bently Nevada |
| Model Number | 330102-00-19-15-11-05 |
| Series | 3300 XL 8 mm |
| Thread Size | 3/8-24 UNF |
| Unthreaded Length (Option AA) | 0.0 in |
| Overall Case Length (Option BB) | 1.9 in |
| Total Length (Option CC) | 1.5 meters (4.9 feet) |
| Connector & Cable Type (Option DD) | Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable |
| Armor Option | Integral stainless steel armor |
| Agency Approvals (Option EE) | CSA, ATEX, IECEx |
| Cable Weight | 323 g/m (11.4 oz/m) |
| Approximate Shipping Weight | 1.5 kg (3.3 lbs) |
During installation, ensure the thread engagement matches the 3/8-24 UNF specification, avoiding over-tightening which can damage the probe case or internal windings. The minimum bend radius of the armored cable must be maintained to prevent damage to the internal coaxial core. Ensure the ClickLoc connector protector is correctly seated and sealed to prevent moisture ingress, which can degrade signal integrity. For optimal calibration, verify compatibility with the corresponding 3300 XL proximitor sensor and extension cable.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330102-00-19-15-11-05
Country of origin:United States
Product Type: Proximity Probes
Payment: T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months
