The 330102-00-20-10-01-05 is a 3300 XL 8 mm proximity probe configuration featuring a 3/8-24 UNF threaded steel body with protective armor, 0.0 in unthreaded length (Option 00), 2.0 in case length (Option 20), and a 1.0 m total system length (Option 10). This probe includes the Miniature coaxial ClickLoc connector with a connector protector (Option 01) and holds CSA, ATEX, and IECEx hazardous area approvals (Option 05).
Designed for use within 3300 XL 8 mm proximity transducer systems, this probe utilizes non-contact eddy-current technology to provide precise displacement measurement. The integrated armor provides mechanical protection for the probe cable in harsh industrial environments, while the ClickLoc connector ensures a secure, reliable connection to the extension cable. This unit is fully compatible with 3300 XL Proximitor sensors and extension cables, facilitating accurate monitoring of shaft vibration and axial position on rotating machinery such as turbines, compressors, and large motors.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330102-00-20-10-01-05 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF, Armored |
| A - Unthreaded Length | 00 | 0.0 in (fully threaded) |
| B - Overall Case Length | 20 | 2.0 in |
| C - Total Length | 10 | 1.0 meter (3.3 feet) |
| D - Connector/Cable | 01 | ClickLoc connector with protector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330102-00-20-10-01-05 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| Case Material | AISI 303 or 304 stainless steel |
| Cable Type | Coaxial, armored |
| Connector | Miniature coaxial ClickLoc |
| Total System Length | 1.0 meter |
| Agency Approvals | CSA, ATEX, IECEx |
Probes should be installed using the appropriate mounting bracket (aluminum or phenolic) to ensure proper spacing and electrical isolation if required. The probe tip must be gapped according to the specific machinery requirements, typically 1.27 mm (50 mil) for standard vibration monitoring. Ensure the armored cable is routed away from high-temperature zones and secured to prevent vibration-induced fatigue. Connector protectors should be fully engaged to prevent moisture and contaminant ingress.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330102-00-20-10-01-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
