The 330103-00-04-10-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread, 0 mm unthreaded length (Option 00), and a 40 mm case length (Option 04). This non-contact eddy-current transducer is a core component of the 3300 XL 8 mm Proximity Transducer System, engineered for precise shaft vibration and axial position measurement in critical rotating machinery. This configuration includes a 1.0 meter system length (Option 10) and a miniature ClickLoc coaxial connector (Option 02) without agency approvals (Option 00).
Designed for integration into the 3300 XL monitoring chain, this probe pairs with the 3300 XL Proximitor sensor and 3300 XL extension cable to provide a complete signal path. The 330103 model is constructed without integrated armor, relying on its rugged M10 x 1 housing for reliable performance in industrial environments. It is suitable for applications where standard M10 metric mounting is required, providing consistent displacement output in varied operating temperatures and mechanical configurations.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-00-04-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 00 | 0 mm unthreaded length |
| B - Case Length | 04 | 40 mm case length |
| C - Total Length | 10 | 1.0 meter system length |
| D - Connector | 02 | Miniature ClickLoc coaxial connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330103-00-04-10-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| System Length | 1.0 meter |
| Connector Type | Miniature ClickLoc coaxial connector |
| Cable Type | Standard (unarmored) |
| Agency Approvals | None (Option 00) |
Ensure correct probe gap settings as specified in the 3300 XL system manual to maintain linearity and measurement range. For M10 x 1 threaded installations, use compatible Bently Nevada mounting brackets. Avoid excessive tightening of the probe body to prevent mechanical damage. Ensure all coaxial connections are secure and protected with connector protectors where environmental exposure is expected. Follow proper grounding and shielding practices for the field wiring to prevent electrical noise interference in the signal loop.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-04-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
