Option 00 (0.0 in unthreaded length) and Option 04 (0.4 in case length) define this 330103-00-04-10-12-00 3300 XL 8 mm proximity probe configuration. This unit utilizes a 1.0 m total system length (Option 10) and is supplied with a miniature click-lock coaxial connector and connector protector (Option 12), providing a robust termination interface for industrial machinery monitoring chains.
The 330103 series probe operates as a non-contact eddy-current displacement transducer within the Bently Nevada 3300 XL 8 mm system. It is engineered to interface with the 3300 XL Proximitor sensor and extension cable, facilitating accurate measurement of shaft vibration and axial position in critical rotating equipment. This unarmored configuration is standard for environments where mechanical abrasion protection is not required.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-04-10-12-00 | 3300 XL 8 mm Proximity Probe, Unarmored |
| A - Unthreaded Length | 00 | 0.0 in (fully threaded) |
| B - Case Length | 04 | 0.4 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 12 | Miniature click-lock connector, includes connector protector |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-04-10-12-00 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF-2A |
| Total System Length | 1.0 m |
| Connector Type | Miniature click-lock coaxial |
| Connector Protector | Included (Option 12) |
| Case Length | 0.4 in (10.2 mm) |
| Linear Range | 2 mm (80 mil) |
| Operating Temperature | -51 degC to +177 degC |
| Agency Approvals | Not required (General purpose) |
Ensure the probe is mounted in a high-quality bracket to prevent mechanical resonance. When routing the extension cable, avoid sharp bends that exceed the minimum bend radius and protect the connector interface using the provided connector protector. Maintain standard clearance gaps per the 3300 XL system documentation to avoid signal clipping. Grounding should follow established site practices for instrument shielding to prevent electromagnetic interference.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-04-10-12-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
