330103-00-05-15-01-00 is a 3300 XL 8 mm proximity probe configuration featuring a 3/8-24 UNF threaded connection, 0.5 in case length (Option 05), 1.5 m total length (Option 15), and standard connector (Option 01) with no agency approval required (Option 00). This probe is engineered for non-contact eddy-current displacement measurement within 3300 XL monitoring chains, providing precise shaft vibration and axial position data in critical rotating machinery applications.
This configuration utilizes a 3/8-24 UNF threaded body, which differs from unthreaded variants in mounting flexibility. When paired with the 330180 Proximitor sensor and 330130 extension cable, this probe maintains full system calibration and linearity across its measurement range. The system design ensures consistent performance in harsh environments where reliable monitoring of rotor position and vibration is critical for machinery health and protection.
| Option | Code on This SKU | Description |
| Orderable Part Number | 330103-00-05-15-01-00 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 05 | 0.5 in |
| C - Total Length | 15 | 1.5 m |
| D - Connector/Cable | 01 | Miniature ClickLoc coaxial connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330103-00-05-15-01-00 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| System Length | 1.5 m |
| Cable Type | Standard coaxial |
| Connector | Miniature ClickLoc |
| Operating Temperature | -51 degC to +177 degC |
| Case Material | AISI 303 or 304 stainless steel |
| Output | 7.87 V/mm (200 mV/mil) |
Ensure the probe is installed with the correct gap voltage, typically set at -10 V DC when centered within the linear range. Secure the probe using the included lock nuts to prevent vibration-induced loosening. Cables should be routed away from high-voltage AC lines to prevent signal interference. Use appropriate conduit or cable protection in high-abrasion environments. Do not exceed the minimum bend radius of the coaxial cable during installation.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-05-15-01-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
