The 330103-00-06-05-02-00 is an 8 mm proximity probe from the 3300 XL transducer system, specifically configured with an M10 x 1 thread and a 60 mm case length. This non-contact, eddy-current displacement transducer is engineered for measuring shaft vibration and axial position on critical rotating machinery. As an unarmored probe configuration, it provides precise signal transmission for monitoring and diagnostic applications where mechanical cable protection is not required.
This unit features a 0.5 meter total system length and a standard miniature coaxial ClickLoc connector, ensuring compatibility with 3300 XL Proximitor sensors and extension cables. The absence of agency approval (Option 00) makes this specific configuration suitable for standard industrial environments where certified hazardous area protection is not mandated.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-06-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 00 | 0 mm unthreaded length |
| B - Case Length | 06 | 60 mm case length |
| C - Total Length | 05 | 0.5 meter total length |
| D - Connector | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-06-05-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Case Length | 60 mm |
| Total Length | 0.5 m |
| Cable Type | Standard coaxial, unarmored |
| Connector | Miniature coaxial ClickLoc |
| Agency Approval | None (Not required) |
Ensure that the probe is installed using the appropriate M10 x 1 mounting bracket. Maintain correct gap distance from the target surface as specified in the 3300 XL system manual. Verify that the cable is routed away from high-noise electrical equipment and secured properly to prevent mechanical stress on the ClickLoc connector. Ensure the probe and extension cable system length matches the 0.5 m calibration of the Proximitor sensor.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-06-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
