Option 00 (0 mm unthreaded), Option 11 (110 mm case length), Option 10 (1.0 m total length), Option 02 (Miniature ClickLoc connector, standard cable), and Option 00 (no agency approval) specify this 330103-00-11-10-02-00 3300 XL 8 mm proximity probe configuration. This non-contact eddy-current displacement probe is designed for use in 3300 XL monitoring systems to provide accurate shaft vibration and axial position measurements in critical rotating machinery.
The 330103 series features a metric M10 x 1 thread and an unarmored construction, making it suitable for applications where mechanical abrasion from armor is not required. This specific variant utilizes a standard miniature coaxial ClickLoc connector and a 1.0 m total system length, compatible with standard 3300 XL Proximitor sensors and extension cables. It is intended for installations where no specific hazardous area certifications (Option 00) are required.
| Option | Code | Description |
| Orderable Part Number | 330103-00-11-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 00 | 0 mm unthreaded length |
| B - Case Length | 11 | 110 mm case length |
| C - Total Length | 10 | 1.0 meter system length |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-11-10-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Case Type | Unarmored |
| Total Length | 1.0 meter |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Agency Approvals | Not required (Option 00) |
Ensure the probe is gapped correctly according to the system manual for the specific machinery application. Use the appropriate M10 x 1 lock nut with safety wire holes to secure the probe position after calibration. Ensure that the extension cable length and probe length, when added together, equal the required Proximitor sensor total length to maintain system calibration accuracy. Protect connectors from environmental contamination during installation.
This unit is supplied with Option 00, indicating no hazardous area agency approvals are required for this specific configuration.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-11-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
