Reverse mount configuration 330103-00-12-15-01-05 specifies this 3300 XL 8 mm proximity probe, designed for shaft vibration and axial position measurement within 3300 XL monitoring systems. This unit features a 0.0 in unthreaded length (Option 00) and a 1.2 in case length (Option 12), with a total system length of 1.5 m (Option 15). The probe uses a miniature coaxial ClickLoc connector (Option 01) and includes CSA, ATEX, and IECEx hazardous area approvals (Option 05).
The 3300 XL 8 mm transducer system consists of a probe, an extension cable, and a Proximitor sensor. This reverse mount probe model is primarily used in applications where the probe must be mounted through a bracket or housing that supports the reverse-style configuration, common in various turbine and compressor monitoring setups. It is fully compatible with existing 3300 XL system components, ensuring signal integrity and measurement accuracy for critical machinery protection.
| Orderable Part Number | 330103-00-12-15-01-05 | 3300 XL 8 mm Proximity Probe |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 12 | 1.2 in |
| C - Total Length | 15 | 1.5 m |
| D - Connector | 01 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx |
| Manufacturer | Bently Nevada |
| Part Number | 330103-00-12-15-01-05 |
| Probe Diameter | 8 mm |
| Mounting Style | Reverse Mount |
| Connector Type | Miniature coaxial ClickLoc |
| Total Length | 1.5 m |
| Operating Temperature | -51 degC to +177 degC |
| Case Material | AISI 303 or 304 stainless steel |
| Tip Material | Polyphenylene sulfide (PPS) |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure the probe is installed in a suitable bracket to maintain the required gap settings as defined by the 3300 XL monitoring system configuration. Use appropriate cable routing to protect the coaxial connector from mechanical stress and abrasion. Verify that the system ground is consistent with Bently Nevada installation manuals for hazardous area locations.
