Bently Nevada

Bently Nevada 330103-00-16-10-02-05 3300 XL 8 mm Proximity Probe

SKU 330103-00-16-10-02-05

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330103-00-16-10-02-05
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330103-00-16-10-02-05 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

330103-00-16-10-02-05: 3300 XL 8 mm proximity probe, configured with a 1.6 inch case length (Option 16), 1.0 m total system length (Option 10), and integrated stainless steel armor for increased mechanical durability. This probe serves as a primary non-contact sensor within the 3300 XL monitoring system, providing continuous voltage output proportional to the gap between the probe tip and the observed conductive surface.

The 330103 configuration utilizes a 3/8-24 UNF thread and is designed for compatibility with 3300 XL Proximitor sensors and extension cables. The inclusion of Option 05 approvals allows for installation in hazardous area environments governed by CSA, ATEX, and IECEx standards. This probe is frequently deployed in critical rotating machinery applications, including steam and gas turbines, centrifugal compressors, and industrial pumps, for shaft vibration and axial position measurement.

Features

  • Option 16: 1.6 in (40 mm) case length for specific mounting depth requirements
  • Option 10: 1.0 m (3.3 ft) total system length, allowing connection to extension cables or direct-to-Proximitor integration
  • Option 02: Miniature ClickLoc connector with standard cable
  • Option 05: Agency approval covering CSA, ATEX, and IECEx hazardous area requirements
  • Integrated stainless steel armor provides protection against abrasive industrial fluids and mechanical damage
  • 8 mm probe tip diameter compatible with standard 3300 XL series monitoring systems

Applications

  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position (thrust) measurement
  • High-abrasion environments where cable protection is required
  • Hazardous area machinery protection

Ordering Information

Orderable Part Number 330103-00-16-10-02-05 3300 XL 8 mm Proximity Probe
A - Unthreaded Length 00 0.0 in
B - Case Length 16 1.6 in
C - Total Length 10 1.0 m
D - Connector/Cable 02 Miniature ClickLoc, standard cable
E - Agency Approval 05 CSA, ATEX, IECEx

Technical Specifications

Manufacturer Bently Nevada
Part Number 330103-00-16-10-02-05
System Type 3300 XL 8 mm Proximity Transducer System
Probe Diameter 8 mm
Thread Size 3/8-24 UNF
Material AISI 303 or 304 Stainless Steel
Linear Range 2 mm (80 mil)
Operating Temperature -51 degC to +177 degC
Agency Approvals CSA, ATEX, IECEx

Installation Guidelines

  • Ensure the probe is mounted in a location free from excessive vibration or physical impact that could damage the cable armor.
  • Maintain the specified gap voltage requirements during calibration to ensure linear output.
  • Use appropriate thread sealing compounds compatible with the industrial fluid environment.
  • Ensure the probe cable is securely routed and supported to prevent strain on the ClickLoc connector.
  • Ground the system according to local hazardous area regulations when Option 05 approvals are required.

Compliance and Certifications

  • CSA: Class I, Division 2, Groups A, B, C, D
  • ATEX: II 1 G Ex ia IIC T90 degC...T105 degC
  • IECEx: Ex ia IIC T90 degC...T105 degC Ga
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the -05 suffix in the model number indicate?
The -05 code indicates that the probe is certified for hazardous area use, specifically meeting CSA, ATEX, and IECEx approval standards.
What is the primary difference between the 330103 and 330101 probes?
The 330103 model features integrated stainless steel armor on the cable for mechanical protection, whereas the 330101 model is the standard version without armor.
Can this probe be connected directly to a monitoring system?
The 330103 probe is designed to work as part of a 3300 XL transducer system, requiring a compatible 3300 XL Proximitor sensor and extension cable to complete the monitoring loop.
