The 330103-01-07-05-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread (Option 01) and an unarmored construction. This probe is a critical component of the 3300 XL 8 mm proximity transducer system, designed for high-precision non-contact eddy-current displacement measurement, including shaft vibration and axial position monitoring in critical rotating machinery.
This specific configuration is defined by a 0.1 in unthreaded length (Option 01), a 0.7 in case length (Option 07), and a 0.5 meter total cable length (Option 05). It utilizes a miniature coaxial ClickLoc connector with a standard cable (Option 02) and is supplied without specific hazardous area agency approvals (Option 00). This probe is designed for seamless integration with 3300 XL Proximitor sensors and 3300 XL extension cables to ensure accurate system-wide performance in demanding industrial environments.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-01-07-05-02-00 | 3300 XL 8 mm Proximity Probe, M10x1, Unarmored |
| A - Unthreaded Length | 01 | 0.1 in unthreaded length |
| B - Case Length | 07 | 0.7 in case length |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330103-01-07-05-02-00 |
| System Type | 3300 XL 8 mm Proximity Transducer |
| Thread Size | M10 x 1 |
| Probe Diameter | 8.0 mm |
| Cable Type | Standard |
| Total Length | 0.5 meter |
| Connector Type | Miniature coaxial ClickLoc |
| Temperature Range | -55 degC to +177 degC (probe tip) |
| Agency Approvals | Not required |
Ensure the probe is gapped according to the 3300 XL system manual for optimal linear range. When routing, secure the cable to prevent mechanical vibration and protect the ClickLoc connector from excessive moisture or contamination. For hazardous area installations, ensure the Proximitor sensor is mounted in a suitable enclosure and that all cabling adheres to relevant site safety drawings.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-01-07-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
