Bently Nevada

Bently Nevada 330103-07-12-10-02-00 3300 XL 8 mm Sonda di prossimità

SKU 330103-07-12-10-02-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330103-07-12-10-02-00
  • Origin United States
  • Product Type: 3300 XL 8 mm Sonda di prossimità
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330103-07-12-10-02-00 3300 XL 8 mm Sonda di prossimità

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The 330103-07-12-10-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread and an unarmored construction. This specific configuration includes a 70 mm unthreaded length (Option 07) and a 120 mm total case length (Option 12). Designed for non-contact eddy-current displacement measurement, it is a key component of the 3300 XL 8 mm Proximity Transducer System, used to monitor shaft vibration and axial position in critical rotating machinery such as turbines, compressors, and motors. This probe configuration is supplied with a 1.0 m system length (Option 10) and features a standard Miniature coaxial ClickLoc connector (Option 02), providing a robust connection to the extension cable and Proximitor sensor. It does not include hazardous area agency approvals (Option 00), making it suitable for standard industrial applications where such certifications are not mandated.

Features

  • M10 x 1 thread size, unarmored probe design
  • 70 mm unthreaded length (Option 07) and 120 mm case length (Option 12)
  • 1.0 meter total system length (Option 10)
  • Miniature coaxial ClickLoc connector with standard cable (Option 02)
  • No hazardous area agency approvals required (Option 00)
  • Compatible with 3300 XL Proximitor sensors and extension cables
  • Designed for continuous monitoring in harsh industrial environments

Applications

  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position measurement
  • Critical rotating machinery protection
  • Fluid film bearing diagnostics
  • Industrial condition monitoring systems

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330103-07-12-10-02-00 3300 XL 8 mm Proximity Probe, M10 x 1 thread
A - Unthreaded Length 07 70 mm unthreaded length
B - Case Length 12 120 mm case length
C - Total Length 10 1.0 meter (3.3 feet)
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval 00 Not required

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Part Number 330103-07-12-10-02-00
Probe Diameter 8 mm
Thread Size M10 x 1
Probe Type Unarmored
Total Length 1.0 meter
Connector Type Miniature coaxial ClickLoc
Cable Type Standard
Operating Temperature -52 Celsius to +177 Celsius
Agency Approvals None (Option 00)

Installation Guidelines

  • Ensure the probe tip is installed within the linear range of the Proximitor sensor setup.
  • Hand-tighten the ClickLoc connectors until firm; do not over-torque.
  • Route cables away from high-voltage lines or sources of electromagnetic interference to maintain signal integrity.
  • Verify thread engagement does not exceed 15 mm for M10 x 1 threads to prevent installation binding.
  • Ensure the Proximitor sensor installation environment meets IP54 protection requirements if applicable.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 07 option represent in this part number?
The 07 option indicates an unthreaded probe length of 70 mm, as M10 threads are specified in 10 mm increments.
Is this probe armored?
No, the 330103 model series is an unarmored probe design.
Can this 1.0 meter probe be used with any Proximitor sensor?
This probe is designed for use within the 3300 XL 8 mm monitoring chain; ensure your Proximitor sensor is compatible with the 1.0 meter system length configuration.
What thread type does this probe use?
This probe uses an M10 x 1 metric thread.
Reviews

More from this brand

Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
168679-01-01-01-02-03-05-01-01-00-02-02Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
3300/50-02-01-00-00Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
3300/16-02-01-01-01-00-00Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor
87890-01Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor

330103-07-12-10-02-00

Stock & lead time on request

Call
  • Bently Nevada 330103-07-12-10-02-00
  • Bently Nevada 330103-07-12-10-02-00
  • Bently Nevada 330103-07-12-10-02-00
1 3

Bently Nevada 330103-07-12-10-02-00 3300 XL 8 mm Sonda di prossimità
