The 330103-07-18-10-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread and an unarmored construction. This specific configuration includes a 70 mm unthreaded length (Option 07) and a 180 mm case length (Option 18), paired with a 1.0 meter total system length (Option 10). The probe is terminated with a miniature coaxial ClickLoc connector and standard cable (Option 02) and is supplied without specific hazardous area agency approvals (Option 00).
As part of the Bently Nevada 3300 XL 8 mm transducer system, this probe is designed for use in critical rotating machinery environments to perform non-contact, eddy-current displacement measurements. It is fully compatible with the 3300 XL Proximitor sensor and 3300 XL extension cables, forming a complete measurement chain for monitoring shaft vibration and axial position on turbines, compressors, and pumps.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-07-18-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1, Unarmored |
| A - Unthreaded Length | 07 | 70 mm |
| B - Case Length | 18 | 180 mm |
| C - Total Length | 10 | 1.0 meter |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330103-07-18-10-02-00 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm (0.31 in) |
| Thread Size | M10 x 1 |
| Armor | None (Unarmored) |
| Case Length | 180 mm |
| Unthreaded Length | 70 mm |
| Total Length | 1.0 m |
| Connector Type | Miniature coaxial ClickLoc |
| Agency Approvals | Not required |
Ensure that the probe gap is set according to the 3300 XL system manual to achieve linear output voltage. When installing, avoid overtightening the probe in the M10 x 1 mounting location. Ensure the cable is properly secured to minimize vibration and protected from physical damage. The probe should be installed in a manner that prevents the connector from being subjected to excessive mechanical stress.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-07-18-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
