Description

The 330104-00-04-50-11-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread and armored cable construction. This configuration is specifically defined by a 0.0 mm unthreaded length (Option 00), a 40 mm case length (Option 04), and a 5.0 m total system length (Option 50). It utilizes a miniature ClickLoc coaxial connector with a connector protector and FluidLoc cable (Option 11), with no additional agency approvals required (Option 00).

This probe is a primary component of the 3300 XL 8 mm Proximity Transducer System, used for non-contact eddy-current displacement measurement on critical rotating machinery. It is designed to work in conjunction with 3300 XL Proximitor sensors and extension cables to monitor shaft vibration, axial position, and speed. The armored cable provides enhanced mechanical protection, while the FluidLoc cable option prevents oil and other liquids from leaking through the cable interior.

Features

• M10 x 1 thread probe body with integral armor for increased abrasion resistance
• 5.0 meter total system length for extended reach applications
• Miniature ClickLoc coaxial connector with connector protector for reliable signal transmission
• FluidLoc cable design to prevent liquid ingress and leakage
• Compatible with standard 3300 XL 8 mm monitoring chains
• 0.0 mm unthreaded length and 40 mm case length configuration

Applications

• Turbine and compressor shaft vibration monitoring
• Rotor axial position measurement
• Critical rotating machinery protection
• Hazardous and non-hazardous industrial environments

Ordering Information

Technical Specifications

Installation Guidelines

Ensure proper probe gapping according to the 3300 XL system manual. When installing probes with armored cables, verify that the armor is properly secured and not subjected to sharp bends. Proximitor sensors should be mounted in a protected enclosure. Use the provided connector protectors to prevent environmental damage to the coaxial interfaces. Avoid installation in areas exceeding the operating temperature range of -55 degC to +177 degC.

Compliance and Certifications

This specific configuration (Option 00) does not include hazardous area agency approvals. Ensure the installation environment complies with local safety regulations and system requirements.
