Product Overview
The Bently Nevada 330104-00-14-05-02-00 is a 3300 XL 8 mm proximity probe designed for precise non-contact shaft vibration and position measurement. Moreover, it delivers stable signal performance in harsh industrial environments, therefore supporting reliable rotating machinery protection and condition monitoring.
Core Features / Highlights
Robust 8 mm eddy current probe design ensures repeatable measurements under continuous vibration and temperature variation.
Moreover, armored cable construction improves mechanical durability and resistance against abrasion in demanding installations.
Miniature coaxial ClickLoc™ connector enables quick, secure connection while reducing installation and maintenance time.
Therefore, M10 × 1 threaded mounting supports precise probe positioning and consistent measurement gap control.
In addition, compatibility with Bently Nevada 3300 XL extension cables and monitors simplifies system standardization.
Technical Specifications / Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model / Part Number | 330104-00-14-05-02-00 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Measurement Principle | Eddy current, non-contact displacement |
| Probe Tip Diameter | 8 mm |
| Thread Size | M10 × 1 |
| Armor | Yes, integral armored cable |
| Unthreaded Length | 0 mm (Option 00) |
| Overall Case Length | 140 mm (Option 14) |
| Total Cable Length | 0.5 m / 1.6 ft (Option 05) |
| Connector Type | Miniature coaxial ClickLoc™ connector |
| Cable Type | Standard coaxial cable |
| Typical Measurement Range | Up to 2.0 mm (80 mils), typical |
| Sensitivity | 7.87 V/mm (200 mV/mil), typical with matched system |
| Frequency Response | 0–10 kHz, typical (system dependent) |
| Operating Temperature | −35 °C to +177 °C, typical |
| Environmental Protection | Industrial sealed design, equivalent to IP67 (typical) |
| Compatible Systems | 3300 XL extension cables and 3300 / 3500 monitoring systems |
| Agency Approvals | Not required (Option 00) |
| Country of Origin | Made in U.S.A |
| Probe Weight | 0.323 kg |
| Shipping Weight | 1.5 kg |
Note: Electrical performance and frequency response are system-dependent and specified as typical values when used with matched 3300 XL components.
Typical Applications / System Integration
This probe is commonly used on turbines, compressors, pumps, motors, and gearboxes for shaft vibration and axial position monitoring. Moreover, it integrates directly into Bently Nevada machinery protection systems, therefore supporting predictive maintenance and reduced unplanned downtime.
