Fully threaded M10 x 1 metric probe body with stainless steel protective armor, 0 mm unthreaded length (Option 00), 140 mm overall case length (Option 14), and a 1.0 m total length (Option 10) — 330104-00-14-10-11-00. This configuration is part of the Bently Nevada 3300 XL 8 mm Proximity Transducer System, which is used for non-contact shaft vibration and axial position measurements in rotating machinery.
This specific variant features Option 11, which includes a miniature ClickLoc coaxial connector with an integrated fluorosilicone connector protector on a FluidLoc cable. The FluidLoc design blocks oil and other industrial fluids from migrating along the inside of the cable, making it ideal for severe oil-exposure environments. With Option 00 for agency approvals, this probe is configured for non-hazardous locations or applications where standard international approvals are not required.
Typically used for monitoring shaft vibration, radial position, and axial position on critical rotating machinery. Applications include steam turbines, gas turbines, compressors, gearboxes, pumps, and electric motors in power generation, chemical processing, and oil and gas industries.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-00-14-10-11-00 | 3300 XL 8 mm Probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 00 | 0 mm unthreaded length |
| B - Overall Case Length Option | 14 | 140 mm overall case length (14 x 10 mm increments) |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) overall length |
| D - Connector and Cable-Type Option | 11 | Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable |
| E - Agency Approval Option | 00 | Not required (standard version) |
| Manufacturer | Bently Nevada |
| Part Number | 330104-00-14-10-11-00 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Thread Size | M10 x 1 metric thread |
| Armor Material | Flexible AISI 302 or 304 stainless steel with FEP outer jacket |
| Cable Type | 75 Ohm triaxial, FluidLoc oil-barrier design |
| Connector Type | Miniature coaxial ClickLoc with fluorosilicone boot |
| Unthreaded Length | 0 mm |
| Case Length | 140 mm |
| Total Probe Length | 1.0 m (3.3 feet) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) for probe tip and cable |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Differential Pressure Seal | Designed to seal differential pressure up to 7.0 bar (100 psi) between probe tip and case |
| Tensile Strength | 330 N (75 lbf) maximum probe case to probe lead; 270 N (60 lbf) lead to connector |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Dimensions | 140 mm x 10 mm x 10 mm (H x W x D) |
| Weight | 0.25 kg |
Ensure the probe mounting location is rigid enough to prevent vibration. When installing, tighten the M10 x 1 threaded probe case to the recommended torque. Avoid bending the armored cable below the minimum bend radius of 25.4 mm (1.0 in). The FluidLoc cable provides protection against fluid migration, but the connector connection should be clean and dry. Keep the probe tip clear of surrounding metal to prevent side-loading calibration errors.
This SKU (Option 00 for Agency Approvals) is standard and does not carry hazardous area certifications. For applications requiring ATEX, IECEx, or CSA approvals, select Option 05 or equivalent certified variants.
