Reverse mount 3/8-24 UNF steel probe body (Option 00) with 1.8 in case length (Option 18) and 1.0 m lead length (Option 10) — 330104-00-18-10-01-05. This configuration utilizes a miniature coaxial ClickLoc connector (Option 01) and includes CSA, ATEX, and IECEx hazardous area approvals (Option 05) as part of the 3300 XL 8 mm Proximity Transducer System.
This 8 mm probe is used for non-contact eddy-current displacement measurement within 3300 XL monitoring chains. It is designed to pair with the 330180 Proximitor sensor and 330130 extension cable to monitor shaft vibration and axial position on critical rotating machinery, including steam and gas turbines, compressors, and centrifugal pumps. The reverse mount design is specifically engineered for installation in confined spaces where probe head access is limited.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-00-18-10-01-05 | 3300 XL 8 mm Proximity Probe, Reverse Mount |
| A - Unthreaded Length | 00 | 0.0 in (fully threaded) |
| B - Case Length | 18 | 1.8 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector | 01 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx |
| Manufacturer | Bently Nevada |
| Part Number | 330104-00-18-10-01-05 |
| Probe Diameter | 8 mm |
| Mounting Style | Reverse Mount |
| Linear Range | 2 mm |
| Temperature Range | -51 degC to +177 degC |
| Body Material | AISI 303 or 304 stainless steel |
| Connector Type | ClickLoc Miniature Coaxial |
| Agency Approvals | CSA, ATEX, IECEx |
| Pin / Interface | Description |
| Center Conductor | Signal Output |
| Coaxial Shield | Common / Ground |
Ensure the probe is installed in a secure, vibration-resistant location. When installing the 330104, verify that the thread engagement does not cause the probe tip to contact the rotating shaft. Use the provided locknut to maintain the required gap setting. Ensure proper shielding of extension cables to prevent electromagnetic interference. In hazardous areas, verify that the installation complies with local safety regulations regarding intrinsic safety barriers and grounding.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-00-18-10-01-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
