Bently Nevada 330104-00-24-10-02-00 3300 XL 8 mm Proximity Probe

SKU 330104-00-24-10-02-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330104-00-24-10-02-00
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330104-00-24-10-02-00 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

330104-00-24-10-02-00 is a 3300 XL 8 mm proximity probe configured with a 0.0 in unthreaded length (Option 00), 2.4 in case length (Option 24), 1.0 m total length (Option 10), and a standard miniature ClickLoc connector (Option 02). This transducer is designed for non-contact eddy-current displacement measurement within 3300 XL 8 mm proximity transducer systems, providing accurate shaft vibration and axial position data for critical rotating machinery.

The 330104 probe features an M10 x 1 thread and includes armor for enhanced mechanical protection in industrial environments. It functions as part of a complete measurement chain, including a 3300 XL Proximitor sensor and an extension cable, ensuring system-wide compatibility and signal integrity. This configuration does not include agency approvals (Option 00).

Features

  • Model: 330104 3300 XL 8 mm proximity probe
  • Thread: M10 x 1 (with armor)
  • Unthreaded Length: 0.0 in (Option 00)
  • Case Length: 2.4 in (Option 24)
  • Total Length: 1.0 m (Option 10)
  • Connector: Miniature coaxial ClickLoc connector (Option 02)
  • Agency Approval: Not required (Option 00)

Applications

  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position measurement
  • Critical rotating machinery protection
  • Industrial environments requiring armored cable protection

Ordering Information

Option Code Description
Orderable Part Number 330104-00-24-10-02-00 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor
A - Unthreaded Length 00 0.0 in
B - Case Length 24 2.4 in
C - Total Length 10 1.0 m
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval 00 Not required

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Part Number 330104-00-24-10-02-00
Probe Diameter 8 mm
Thread Size M10 x 1
Cable Type Armored
Connector Type Miniature coaxial ClickLoc
Total Length 1.0 m
Agency Approval Not required

Installation Guidelines

  • Ensure proper probe gap settings as specified in the 3300 XL Proximity Transducer System manual.
  • Use appropriate brackets (e.g., aluminum or phenolic threaded mounting brackets) for secure installation.
  • Route cables in dedicated conduit or protected raceways to prevent mechanical damage.
  • Maintain shield integrity throughout the measurement chain to ensure signal accuracy.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 00 option for Agency Approval mean on this 330104 probe?
The 00 option indicates that this specific unit does not have hazardous area certifications (e.g., CSA, ATEX, IECEx) and is intended for use in non-hazardous locations.
Can this 330104 probe be used with a 5-meter Proximitor sensor?
No. This probe has a 1.0 m total length (Option 10) and is designed to be matched with a 1.0 m extension cable to meet the 9.0-meter system length requirement or other compatible lengths. Probes with different total lengths must be matched with the correct Proximitor sensor length.
Does the 330104-00-24-10-02-00 include an armored cable?
Yes, the 330104 model is an armored 8 mm proximity probe, providing enhanced protection against physical damage in industrial settings.
