330104-02-21-10-01-00 is an 8 mm M10 x 1 threaded 3300 XL proximity probe configured with 20 mm unthreaded length (Option 02) and 210 mm case length (Option 21). This probe features integrated armor for mechanical protection and includes a 1.0 m total length (Option 10) with a Miniature ClickLoc connector and connector protector (Option 01). It is designed for use in 3300 XL 8 mm monitoring chains for non-contact shaft vibration and axial position measurement.
The 330104 series utilizes a metric M10 x 1 thread for installation in machinery housings. The inclusion of an armored cable provides additional resistance to abrasion and environmental hazards common in industrial rotating machinery applications. As an agency-free configuration (Option 00), this probe is intended for non-hazardous locations or applications where specific certifications are not mandated by the site safety plan.
| Option | Code | Description |
| Orderable Part Number | 330104-02-21-10-01-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, armored |
| A - Unthreaded Length | 02 | 20 mm |
| B - Case Length | 21 | 210 mm |
| C - Total Length | 10 | 1.0 meter (3.3 feet) |
| D - Connector/Cable | 01 | Miniature ClickLoc, standard cable, with connector protector |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330104-02-21-10-01-00 |
| Probe Diameter | 8.0 mm |
| Thread Size | M10 x 1 |
| Armor | Included |
| Unthreaded Length | 20 mm |
| Case Length | 210 mm |
| Total Length | 1.0 m |
| Connector Type | Miniature ClickLoc with connector protector |
| Cable Type | Standard |
| Agency Approval | None (Not required) |
| Operating Temperature | -52 degC to +177 degC |
Ensure the probe is gapped correctly according to the 3300 XL system manual to maintain the linear range of the transducer. The M10 x 1 threaded body should be tightened within the maximum engagement limits to prevent binding. Route the armored cable to avoid sharp bends and secure it at regular intervals. Verify that the connector is clean and free of moisture before connecting it to the extension cable or Proximitor sensor; hand-tighten the ClickLoc connector firmly.
