The 330104-03-06-05-02-00 is an 8 mm 3300 XL proximity probe featuring an M10 x 1 thread with armored cable construction, designed for reliable non-contact eddy-current displacement measurement. This specific configuration includes a 30 mm unthreaded length (Option 03), a 60 mm case length (Option 06), a 0.5 meter total system length (Option 05), and a standard miniature coaxial ClickLoc connector (Option 02) without hazardous area approvals (Option 00).
Engineered for the 3300 XL Proximity Transducer System, this probe provides accurate shaft vibration and position monitoring data in demanding industrial environments. The inclusion of an armored cable provides additional physical protection against abrasion or environmental hazards typical in rotating machinery applications. It is fully compatible with 3300 XL Proximitor sensors and extension cables, ensuring linear signal output and consistent system performance.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-03-06-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1, Armored |
| A - Unthreaded Length | 03 | 30 mm |
| B - Case Length | 06 | 60 mm |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Model | 330104 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Cable Type | Armored |
| Connector Type | Miniature coaxial ClickLoc |
| System Length | 0.5 meter |
| Agency Approvals | Not required |
Ensure the probe is gapped correctly according to the 3300 XL system manual to maintain the linear operating range. Use the appropriate threaded mounting bracket (e.g., M10 x 1) and secure with locking nuts. Ensure the armored cable is routed away from high-temperature zones and avoid sharp bends that could compromise the cable integrity. Grounding must be verified at the Proximitor sensor installation point.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-03-06-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
