Bently Nevada

Bently Nevada 330104-13-20-10-02-05 3300 XL 8 mm Proximity Probe

SKU 330104-13-20-10-02-05

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330104-13-20-10-02-05
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330104-13-20-10-02-05 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

330104-13-20-10-02-05 is a 3300 XL 8 mm proximity probe configuration featuring an M10 x 1 threaded body with integrated armor for mechanical protection. This specific model includes a 130 mm unthreaded length (Option 13) and a 200 mm total case length (Option 20). It provides a 1.0 m total system length (Option 10) and is equipped with a miniature ClickLoc coaxial connector without a connector protector (Option 02). This unit is certified for use in hazardous environments, including CSA, ATEX, and IECEx locations (Option 05).

As part of the 3300 XL 8 mm proximity transducer system, this probe is designed for non-contact eddy-current displacement measurement, making it ideal for monitoring shaft vibration and axial position on critical rotating machinery such as turbines and compressors. The system is fully compatible with 3300 XL Proximitor sensors and extension cables, ensuring high-accuracy signal transmission in demanding industrial applications.

Features

  • M10 x 1 threaded stainless steel probe body with integral armor (Option 13/20).
  • Miniature ClickLoc coaxial connector (Option 02).
  • 1.0 meter total system length (Option 10).
  • Hazardous area approvals: CSA, ATEX, and IECEx (Option 05).
  • Designed for seamless integration into 3300 XL monitoring chains.
  • Consistent, repeatable non-contact displacement measurement for vibration and position.

Applications

  • Turbine and generator shaft vibration monitoring.
  • Compressor rotor axial position measurement.
  • Critical rotating machinery protection in oil and gas, power generation, and petrochemical facilities.
  • Industrial environments requiring hazardous area compliance.

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330104-13-20-10-02-05 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor
A - Unthreaded Length 13 130 mm (per PDF)
B - Case Length 20 200 mm (per PDF)
C - Total Length 10 1.0 meter (3.3 feet)
D - Connector 02 Miniature ClickLoc connector, standard cable
E - Agency Approval 05 CSA, ATEX, IECEx Approvals

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Model 330104 (3300 XL 8 mm Proximity Probe)
Thread Size M10 x 1
Probe Case With armor
Total Length 1.0 m
Connector Type Miniature ClickLoc
Agency Approvals CSA, ATEX, IECEx

Installation Guidelines

  • Ensure the total system length (probe + extension cable) matches the Proximitor sensor's calibrated length requirement.
  • Use the provided mounting brackets (ordered separately) to ensure proper positioning and electrical isolation if required.
  • Ensure the probe tip is installed at the correct gap distance according to the transducer system manual.
  • Protect all connectors using recommended connector protectors in environments where contamination or moisture may be present.
  • Follow all local hazardous area regulations and guidelines for cable routing and installation.

Compliance and Certifications

  • CSA (Canadian Standards Association)
  • ATEX (Atmospheres Explosibles)
  • IECEx (International Electrotechnical Commission Explosive)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 13 in the 330104-13-20-10-02-05 part number represent?
The 13 indicates an unthreaded length of 130 mm for this probe configuration.
Is this 330104 probe compatible with non-armored extension cables?
While technically compatible, Bently Nevada recommends using matching armored extension cables if the probe itself is armored to maintain consistent mechanical protection throughout the measurement chain.
Does this probe require special hazardous area installation?
Yes, the 05 approval option indicates this probe is CSA, ATEX, and IECEx approved. Installation must strictly follow the site-specific hazardous area wiring and grounding procedures outlined in the 3300 XL datasheet and user manual.
What is the thread type for the 330104 series?
The 330104 series probes are specifically manufactured with M10 x 1 metric threads.
