The 330105-02-12-05-02-05 is a 3300 XL 8 mm reverse mount proximity probe designed for critical machinery vibration and axial position monitoring. This configuration features a 3/8-24 UNF thread, a 1.2 inch case length, and a 0.5 meter total length with a standard miniature ClickLoc connector. Certified with Option 05 (CSA, ATEX, IECEx), this probe is suitable for hazardous area installations where reliable non-contact displacement measurement is required for sleeve-bearing or fluid-film bearing machinery.
Reverse mount probes like the 330105 are specifically engineered for applications where the probe must be installed through the machine case or housing, requiring the cable to exit through the rear of the probe body. The 3300 XL system, comprising this probe, a 330180 Proximitor sensor, and a 330130 extension cable, provides high-accuracy, linear output for monitoring shaft vibration and position in industrial rotating equipment such as steam turbines, gas compressors, and large centrifugal pumps.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330105-02-12-05-02-05 | 3300 XL 8 mm Reverse Mount Probe |
| A - Unthreaded Length/Mounting | 02 | Specific configuration for 330105 Reverse Mount |
| B - Case Length | 12 | 1.2 inch case length |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 02 | Miniature ClickLoc connector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 330105 |
| Probe Diameter | 8 mm |
| Mounting Type | Reverse Mount |
| Thread | 3/8-24 UNF-2A |
| Total Length | 0.5 m |
| Connector | Miniature ClickLoc |
| Cable Type | Standard (Non-FluidLoc) |
| Agency Approvals | CSA, ATEX, IECEx |
| Linear Range | 2 mm (80 mils) |
| Temperature Range | -55 degC to +177 degC (probe tip) |
Ensure the probe is installed in accordance with Bently Nevada installation drawings for the specific hazardous area classification (e.g., 141092 for ia). When mounting in hazardous locations, ensure the Proximitor sensor provides terminals with at least IP54 protection. Reverse mount probes should be tightened securely through the machine housing, ensuring that the unthreaded length and probe gap are correctly set to maintain linear measurement accuracy.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330105-02-12-05-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Reverse Mount Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
