Option 05 (5.0 mm unthreaded length), Option 30 (30 mm overall case length), and Option 50 (5.0 m total length) specify this 3300 XL 8 mm reverse mount proximity probe configuration — 330106-05-30-50-02-00.
This probe features metric M10 x 1 threads and is used with a 3300 XL Proximitor sensor and extension cable. The reverse mount design is suited for applications where the probe must be installed from the rear or inside a housing. This configuration uses a 5.0 m standard coaxial cable with a miniature ClickLoc connector, bypassing the need for a connector protector. Unlike sibling variants that require agency approvals, this model is specified without hazardous area certifications (Option 00).
| Option Segment | Code on This SKU | Meaning / Description |
|---|---|---|
| Orderable Part Number | 330106-05-30-50-02-00 | 3300 XL 8 mm reverse mount proximity probe, M10 x 1 thread |
| A - Unthreaded Length | 05 | 5.0 mm unthreaded length |
| B - Overall Case Length | 30 | 30 mm overall case length |
| C - Total Length | 50 | 5.0 meters (16.4 feet) |
| D - Connector and Cable-Type | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330106-05-30-50-02-00 |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Thread Specification | M10 x 1 metric thread |
| Unthreaded Length (Segment A) | 5.0 mm (0.20 in) |
| Overall Case Length (Segment B) | 30 mm (1.2 in) |
| Total Length (Segment C) | 5.0 meters (16.4 feet) |
| Connector Type (Segment D) | Miniature coaxial ClickLoc male connector |
| Cable Type | 75 Ohm coaxial cable, standard outer jacket |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Probe Pressure Rating | Seals differential pressure between tip and case (Viton O-ring) |
| Weight | 0.32 kg |
| Dimensions | 10 mm x 10 mm x 30 mm (H x W x D) |
| Connector Component | Specification details |
|---|---|
| Connector Type | Miniature male coaxial ClickLoc connector |
| Contacts | Gold-plated brass / gold-plated beryllium copper |
| Recommended Torque | Finger tight for ClickLoc mating interface |
This specific configuration (Option 00) does not carry hazardous area certifications (unapproved). It is intended for general-purpose applications where certified safety barriers or explosion-proof ratings are not required.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330106-05-30-50-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Reverse Mount Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 320g
Dimensions: 10 mm x 10 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
