Option 040 (4.0 m cable length) and Option 03 (armored cable with connector protector) define this configuration of the 330130-040-03-00, a 3300 XL standard extension cable from Bently Nevada. This cable extends the connection between a 3300 XL 8 mm proximity probe and a 3300 XL Proximitor sensor, transmitting high-frequency eddy-current signals for static position and dynamic vibration monitoring on rotating machines.
This configuration features protective stainless steel armor over the 75-ohm coaxial line to guard against physical wear, abrasion, and mechanical stress in challenging industrial environments. It includes a factory-installed fluorosilicone connector protector on the female coaxial end, which shields the ClickLoc connection from oil, water, and other contaminants. Since Option 00 specifies no agency approvals, this model is configured for general-purpose applications where hazardous area certifications are not required.
| Option Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Orderable Part Number | 330130-040-03-00 | 3300 XL Standard Extension Cable, Armored with Connector Protector, 4.0 Meters |
| A - Cable Length Option | 040 | 4.0 meters (13.1 feet) length |
| B - Connector Protector and Cable Option | 03 | Armored cable with pre-installed connector protector |
| C - Agency Approval Option | 00 | No hazardous area approval required |
| Manufacturer | Bently Nevada |
| Part Number / SKU | 330130-040-03-00 |
| Product Series | 3300 XL 8 mm Proximity Transducer System |
| Cable Type | 75-ohm triaxial, fluorinated ethylene propylene (FEP) insulated |
| Armor Material | Flexible AISI 302 or 304 stainless steel with FEP outer jacket |
| Connector Type | Gold-plated brass ClickLoc coaxial connectors |
| Connector Protector Material | Fluorosilicone (installed on female end) |
| Cable Length | 4.0 meters (13.1 feet) |
| Cable Diameter (Standard) | 3.7 mm maximum outside diameter |
| Cable Diameter (Armored) | 7.67 mm maximum outside diameter |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Operating Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) |
| Relative Humidity Limit | Less than 3 percent change in Average Scale Factor (ASF) in 93 percent humidity per IEC 68-2-3 |
| Tensile Strength (Max Rated) | 330 N (75 lbf) probe case to lead; 270 N (60 lbf) at connectors |
| Dimensions | 250 mm x 250 mm x 45 mm (H x W x D) |
| Weight | 0.45 kg |
