The 330130-075-02-05 extension cable is a critical component of the 3300 XL 8 mm proximity transducer system, designed to facilitate reliable signal transmission between the proximity probe and the Proximitor sensor. This specific configuration features a total cable length of 7.5 meters (Option 075), includes a standard cable with a connector protector (Option 02), and meets hazardous area requirements with CSA, ATEX, and IECEx agency approvals (Option 05).
This extension cable is engineered for use in demanding industrial environments to monitor shaft vibration and axial position on critical rotating machinery such as turbines, compressors, and pumps. It ensures electrical continuity and environmental protection for the transducer chain. When installing, verify that the combined length of the probe and extension cable matches the calibrated total system length required by your 3300 XL Proximitor sensor.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330130-075-02-05 | 3300 XL Standard Extension Cable |
| A - Cable Length | 075 | 7.5 meters (24.6 feet) |
| B - Connector/Cable | 02 | Standard cable with connector protector |
| C - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 330130 3300 XL Standard Extension Cable |
| Cable Length | 7.5 meters |
| Cable Type | Standard coaxial |
| Connector | Miniature coaxial ClickLoc |
| Connector Protection | Included (Option 02) |
| Agency Approvals | CSA, ATEX, IECEx (Option 05) |
Ensure that the extension cable is routed away from high-voltage cables and sources of electromagnetic interference. When connecting the cable to the probe and Proximitor, use the provided connector protectors to ensure an environmental seal. Tighten connectors to finger-tight; do not use excessive force. Ensure the cable is secured at appropriate intervals to prevent vibration-induced wear or damage.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330130-075-02-05
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
