Bently Nevada 330185-02 3300 XL Precision Micrometer

SKU 330185-02

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330185-02
  • Origin United States
  • Product Type: 3300 XL Precision Micrometer
  • Payment: T/T, Western Union
  • Weight: 6.8 kg
  • Dimensions: 226 mm x 274 mm x 356 mm (H x W x L)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Precision Micrometer

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330185-02 3300 XL Precision Micrometer

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Bently Nevada 330185-02 is a 3300 XL Precision Micrometer configured in metric units (0–25 mm). It serves as a verification tool designed for acceptance testing and performance verification of eddy current proximity transducer systems according to original published specifications or American Petroleum Institute standard API 670.

The device checks transducer system performance by holding a probe in a dedicated mounting adapter while moving a high-precision AISI 4140 steel target button toward or away from the probe tip in measured increments, simulating shaft movement. By reading the corresponding output voltage from the Proximitor Sensor using a voltmeter, users can generate a voltage-versus-gap curve to evaluate linear range, average scale factor (ASF), incremental scale factor (ISF), and deviation from straight line (DSL). Additionally, the system provides verification capabilities for shaft position monitoring equipment.

Features

  • High-Precision Calibration: Designed for precise measurement and curve generation to verify transducer linear range, ASF, ISF, and DSL specifications.
  • Standardized Target Material: Utilizes a precision ground AISI 4140 alloy steel target button to match standard machinery target characteristics.
  • Modular Probe Adapters: Accommodates various probe thread sizes including 1/4 inch, 3/8 inch, 1/2 inch, 5/8 inch, M8, M10, M14, and M16 using standard mounting collets/adapters.
  • Standard Compliance: Facilitates field or laboratory verification testing compliant with API 670 guidelines.

Applications

  • Field verification of proximity probe and Proximitor Sensor transducer systems.
  • Factory and laboratory acceptance testing of 3300 XL transducer components.
  • Calibration and operation verification of shaft position and machinery protection monitors.

Ordering Information

Part Number Option Description
330185 -AXX 3300 XL Precision Micrometer
  -01 Micrometer in English units (0-1 in)
  -02 Micrometer in metric units (0-25 mm)

Technical Specifications

Parameter Value
Manufacturer Bently Nevada
Model 330185-02
Measurement Range 0 to 25 mm
Resolution 0.0005 mm
Accuracy + 0.0004 mm
Target Button Material AISI 4140 Alloy Steel, 30.5 mm (1.20 in) diameter flat target
Casing Material Fiberglass and Plastic
Case Dimensions (H x W x L) 226 mm x 274 mm x 356 mm (8.9 in x 10.8 in x 14.0 in)
Total System Weight 6.8 kg (14.5 lb)

Installation Guidelines

  • Probe Setup: Select the correct probe mounting adapter corresponding to the probe thread size (e.g., M8, M10, 3/8 inch) and secure the probe firmly in the holder.
  • Zero Calibration: Verify target button condition and clean the surface before zeroing or commencing measurements.
  • Mechanical Stability: Ensure the unit is positioned on a flat, stable, vibration-free surface during test procedures to prevent reading variations.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the measurement range and resolution of the device?
The device features a measurement range of 0 to 25 mm with a resolution of 0.0005 mm and an accuracy of + 0.0004 mm.
What target material is used for transducer verification?
It utilizes a high-precision AISI 4140 alloy steel flat target button with a diameter of 30.5 mm (1.20 in).
What probe thread sizes can be mounted with the included adapters?
The micrometer supports probe mounting adapters for 1/4 inch, 3/8 inch, 1/2 inch, 5/8 inch, M8, M10, M14, and M16 probe thread sizes.
Reviews

More from this brand

Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
168679-01-01-01-02-03-05-01-01-00-02-02Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
3300/50-02-01-00-00Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
3300/16-02-01-01-01-00-00Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor
87890-01Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor
