Bently Nevada 330190-045-00-00 is a 3300 XL Extended Temperature Range (ETR) extension cable designed for vibration monitoring systems operating in thermally demanding industrial environments. It is commonly used in turbines, compressors, and process machinery where stable signal transmission must be maintained under elevated temperature conditions.
This cable supports reliable data transfer between proximity probes and monitoring modules while minimizing signal drift caused by thermal stress. It is applied in power generation, oil and gas, and heavy industrial systems where temperature stability directly affects machine protection accuracy.
The 4.5 meter configuration provides flexible routing in compact and mid-range machinery installations.
| Element | Description |
|---|---|
| 330190 | 3300 XL ETR extension cable series |
| 045 | 4.5 m cable length |
| 00 | No additional cable option required |
| 00 | No agency approval required |
Each parameter defines cable length and configuration level within the ETR extension cable family.
| Parameter | Specification |
|---|---|
| Model | 330190-045-00-00 |
| Brand | Bently Nevada |
| Origin | United States |
| Weight | 1.5 kg |
| Product Type | Extended temperature range extension cable |
| Cable Length | 4.5 m |
| Cable Construction | Triaxial ETR design |
| Application | Proximity probe signal transmission |
| Operating Environment | High temperature industrial systems |
| System Compatibility | Bently Nevada 3300 XL series |
The ETR cable design maintains stable electrical characteristics under elevated temperature conditions where standard extension cables may experience signal drift or insulation degradation.
Triaxial construction ensures low-noise signal transmission and stable impedance performance, which is critical for accurate vibration monitoring in rotating machinery.
The cable is optimized for integration in high-temperature zones such as turbine casings and compressor housings.
Where is this cable used?
It is used in turbines, compressors, and high-temperature industrial machinery.
What is the benefit of ETR design?
It ensures stable signal performance under elevated thermal conditions.
Is it compatible with standard 3300 XL systems?
Yes. It integrates into the 3300 XL monitoring architecture.
Does cable length affect performance?
Within specification, 4.5 m length maintains stable signal transmission.
Avoid routing near high-temperature steam lines exceeding rated limits.
Maintain proper separation from high-power electrical cables to reduce EMI interference.
Ensure correct connector engagement to maintain signal stability.
Use appropriate cable supports to prevent mechanical stress in high-vibration areas.
Maintain minimum bend radius to protect triaxial shielding integrity.
Inspect insulation condition during scheduled maintenance in high-heat environments.
Ensure proper grounding of shielding for optimal noise suppression.
Avoid direct contact with hot surfaces or radiant heat sources.
