330901-00-65-05-02-05 specifies this 3300 NSv proximity probe configuration featuring a 1/4-28 UNF thread without armor, 0.0 inches of unthreaded body, a 6.5-inch case length, and a 0.5-meter total cable length. This non-contacting displacement probe uses an eddy-current measurement field to monitor shaft vibration and axial position in critical industrial machinery. This configuration is built with a standard coaxial cable terminating in a miniature male ClickLoc connector and includes international multiple approvals (CSA, ATEX, IECEx) for hazardous areas.
The 3300 NSv transducer system is applied in tight-clearance situations where target geometries are extremely small or clearances are restricted, allowing installation on smaller machinery shafts that cannot accommodate standard 8 mm probes. While standard probes require larger target areas, the 3300 NSv series operates with a shaft diameter as small as 8.9 mm (0.35 inches), providing precise proximity measurement for aeroderivative gas turbines, centrifugal compressors, and other high-speed rotating equipment.
| Option Segment | Code Value | Segment Description |
|---|---|---|
| Base Model | 330901 | 3300 NSv Proximity Probe, 1/4-28 UNF thread, without armor |
| A - Unthreaded Length Option | 00 | 0.0 inches unthreaded length |
| B - Overall Case Length Option | 65 | 6.5 inches case length (Order in 0.1-inch increments) |
| C - Total Length Option | 05 | 0.5 meters (20 inches) total length |
| D - Connector & Cable-Type Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 05 | Multiple Approvals (including CSA, ATEX, and IECEx) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330901-00-65-05-02-05 |
| Thread Size | 1/4-28 UNF-2A |
| Armor Configuration | Without armor |
| Unthreaded Length | 0.0 in (0 mm) |
| Case Length | 6.5 in (165 mm) |
| Total Length | 0.5 m (20 in) |
| Connector Type | Miniature male coaxial ClickLoc connector |
| Cable Type | 75 ohm standard coaxial cable |
| Linear Range | 1.5 mm (60 mils) starting at 0.25 mm (10 mils) gap |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) |
| Deviation from Best Fit Straight Line (DSL) | Less than +/-0.06 mm (+/-2.3 mils) |
| Operating Temperature (Probe) | -52 degC to +177 degC (-62 degF to +351 degF) |
| Pressure Seal Rating | Viton O-ring pressure seal (sustained exposure below -34 degC can cause seal wear) |
| Frequency Response | 0 to 10 kHz (+0, -3 dB typical) |
| Recommended Minimum Target Size | 13 mm (0.5 in) diameter (8.9 mm / 0.35 in absolute minimum) |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Tensile Strength Limit | 220 N (50 lb) case-to-lead or connector-to-connector |
| Maximum Recommended Case Torque | 5.1 N-m (45 in-lb) recommended, 7.3 N-m (65 in-lb) maximum rated |
| Connector Component | Function Description |
|---|---|
| Coaxial Center Conductor | Transmits high-frequency RF signal from the Proximitor to the probe tip |
| Coaxial Outer Shield | Serves as the common return path and provides shielding against EMI/RFI |
| ClickLoc Miniature Male Connector | Provides a secure, quick-locking connection to the female end of the extension cable |
| Hazardous Area Approvals (Option 05) | Multiple global approvals including CSA, ATEX, and IECEx |
| Intrinsic Safety (Ex ia) | Ex ia IIC T5...T1 Ga / Ex ia IIIC T90 degC...T280 degC Dc (Class I, Div 1, Groups A, B, C, D) |
| Non-Sparking (Ex nA / Ex ec) | Ex nA IIC T5...T1 Gc / Ex ec IIC T5...T1 Gc (Class I, Div 2, Groups A, B, C, D) |
| Electromagnetic Compatibility (EMC) | CE compliant for RFI/EMI immunity when paired with matching 3300 XL NSv Proximitor |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330901-00-65-05-02-05
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
