The 330905-00-10-10-02-CN is a 3300 XL NSv Proximity Probe configured for M10x1 threads without armor. This transducer system is engineered for non-contact displacement measurement, specifically for applications involving small-bore machinery or limited target areas where standard proximity probes might experience interference or insufficient linear range. This unit features a 0.0 inch unthreaded length (Option 00), 1.0 inch case length (Option 10), and a 1.0 meter total system length (Option 10). The connection is facilitated via a standard miniature coaxial ClickLoc connector (Option 02).
This configuration includes the -CN suffix, signifying that the unit is compliant with China hazardous area approval packages (NEPSI/CCC). The 3300 NSv system is designed to provide high-precision vibration and axial position monitoring on high-speed equipment, aeroderivative turbines, and small-bore compressors. It must be utilized as part of a complete 3300 NSv system, which typically includes the matched 330980 Proximitor Sensor and 330930 extension cable.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330905-00-10-10-02-CN | 3300 NSv Proximity Probe, M10x1 Thread, Unarmored |
| A - Unthreaded Length | 00 | 0.0 inch |
| B - Case Length | 10 | 1.0 inch |
| C - Total Length | 10 | 1.0 meter |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| Suffix | -CN | China hazardous area approval package |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 330905 |
| Thread Size | M10x1 |
| Probe Type | NSv (Near-field / Small target) |
| Armor | None |
| Cable Type | 75 Ohm coaxial, FEP insulated |
| Connector | Miniature coaxial ClickLoc |
| System Length | 1.0 meter |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel |
| Temperature Range | -55 degC to +177 degC (Probe only) |
Ensure the probe is mounted using the correct thread pitch (M10x1). Use the 3300 NSv Connector Kit for proper assembly of ClickLoc connectors. Protect connectors from the environment using the appropriate connector protectors (e.g., silicone self-fusing tape). When installing in hazardous areas, refer to the applicable Bently Nevada installation drawings (e.g., 141092 for IS or 140979 for non-incendive installations) to ensure compliance. Avoid sharp bends in the coaxial cable to prevent impedance changes.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330905-00-10-10-02-CN
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
