The Bently Nevada 9200-06-05-05-00 is a two-wire velocity transducer designed for continuous monitoring or periodic diagnostics of absolute casing, bearing housing, or structural vibration. Utilizing moving-coil technology, this instrument generates a voltage output directly proportional to the transducer's vibration velocity without requiring external operating power. The unique mechanical architecture of the 9200-06-05-05-00 ensures low sensitivity to impact or impulsive excitation, delivering highly reliable and repeatable dynamic data on critical machinery such as turbines, pumps, and industrial fans.
| Option / Code | Factory Configuration Profile |
|---|---|
| 9200 | Two-wire Seismoprobe Velocity Transducer |
| -06 | Transducer Mounting Angle/Minimum Operating Frequency: 0 ±100, 10 Hz (600 cpm) |
| -05 | Connector Option: Terminal block top mount |
| -05 | Mounting Base Option: No base; 1/2-in 20 UNF-3A stud |
| -00 | Agency Approval Option: No approvals required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 9200-06-05-05-00 |
| Product Type | Two-Wire Velocity Seismoprobe Transducer |
| Sensitivity | 20 mV/mm/s (500 mV/in/s) ±5% at +22 Celsius (+72 Fahrenheit) with 25 mm/s (1 in/s) vibration at 100 Hz into a 10 kΩ load |
| Frequency Response | 10 Hz to 1 kHz (60,000 cpm); +0, -3dB typical |
| Operating Orientation | 0 ±100 (Vertical, viewed from driver end) |
| Dynamic Operating Range | 2.54 mm (0.100 in) peak-to-peak maximum displacement |
| Shock Resistance | Withstands 50 g peak maximum acceleration along non-sensitive axis |
| Transverse Sensitivity | ±10% maximum |
| Maximum Leadwire Length | 305 meters (1,000 feet) between transducer and 3300 or 3500 Monitor |
| Operating/Storage Temperature | -29 Celsius to +121 Celsius (-20 Fahrenheit to +250 Fahrenheit) |
| Relative Humidity | Up to 95%, non-condensing |
| Case Material | Anodized aluminum A204 |
| Gasket Material | Neoprene |
| Connector Material | Polyphenylene Sulfide with nickel-plated copper contacts |
| Mounting Base Option | No base; 1/2-in 20 UNF-3A stud |
| Mounting Torque | 5.6 Nm (50 in-lb) |
| Height | 78.54 mm (3.092 in) typical |
| Diameter | 41.40 mm (1.63 in) |
| Weight | 300 grams (10.5 ounces) typical |
| Country of Origin | U.S.A. |
| Connector Pin / Terminal | Function |
|---|---|
| Terminal A | Positive Output (Pin A goes positive with respect to Pin B when case velocity is toward connector) |
| Terminal B | Negative Return |
What does the 05 mounting base configuration indicate?
The -05 code indicates that the transducer is supplied with no separate circular or rectangular flange base; instead, it features an integrated 1/2-in 20 UNF-3A threaded stud directly on the bottom for mounting.
What is the minimum operating frequency limits of this velocity sensor?
This model incorporates the -06 frequency option, establishing a low-end frequency limit of 10 Hz (600 cpm) before signal attenuation starts.
How does the moving-coil principle benefit this transducer over standard accelerometers?
Because it utilizes moving-coil technology rather than solid-state integration crystals, it is substantially more resilient and less sensitive to mechanical impacts or abrupt impulsive shocks.
Is an external power supply or charge amplifier required for wiring?
No, this two-wire velocity system is entirely self-generating and creates a direct voltage output signal from the internal coil movement, making it highly versatile for portable and diagnostic tasks.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 9200-06-05-05-00
Country of origin:United States
Product Type: Seismoprobe Velocity Transducers
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 300g
Dimensions: 9.2cm x 4cm x 4cm
Shipping port: Xiamen
Warranty: 12 months
