The Bently Nevada 9200-06-05-10-00 is a two-wire velocity transducer engineered for continuous monitoring or periodic measurements of absolute structural, casing, or bearing housing vibration. Operating via moving-coil technology, this system delivers a voltage output directly proportional to the mechanical vibration velocity without requiring an external power source. The 9200-06-05-10-00 configuration is specifically less sensitive to impact or impulsive excitation compared to solid-state sensors, making it ideal for standard casing velocity applications across critical machinery like turbines, fans, and pumps.
| Option / Code | Factory Configuration Profile |
|---|---|
| 9200 | Two-wire Seismoprobe Velocity Transducer |
| -06 | Transducer Mounting Angle/Minimum Operating Frequency: 0 ±100, 10 Hz (600 cpm) |
| -05 | Connector Option: Terminal block top mount |
| -10 | Mounting Base Option: Circular; M10X1 stud |
| -00 | Agency Approval Option: No approvals required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 9200-06-05-10-00 |
| Product Type | Two-Wire Velocity Seismoprobe Transducer |
| Sensitivity | 20 mV/mm/s (500 mV/in/s) ±5% at +22 Celsius with 25 mm/s of casing vibration at 100 Hz under 10 kΩ load |
| Frequency Response | From 10 Hz to 1 kHz (60,000 cpm); +0, -3dB typical |
| Operating Orientation | 0 ±100 (Vertical, viewed from driver end) |
| Dynamic Range | 2.54 mm (0.100 in) peak-to-peak maximum displacement |
| Shock Resistance | Withstands 50 g peak maximum acceleration along non-sensitive axis |
| Transverse Sensitivity | ±10% maximum |
| Maximum Leadwire Length | 305 meters (1,000 feet) between transducer and 3300/3500 Monitor |
| Operating Temperature | -29 Celsius to +121 Celsius (-20 Fahrenheit to +250 Fahrenheit) |
| Relative Humidity | Up to 95%, non-condensing |
| Case Material | Anodized aluminum A204 |
| Gasket Material | Neoprene |
| Connector Type | Terminal block top mount (Polyphenylene Sulfide with nickel-plated copper contacts) |
| Mounting Base | Circular; M10X1 stud |
| Mounting Torque | 5.6 Nm (50 in-lb) |
| Height | 78.54 mm (3.092 in) typical |
| Diameter | 41.40 mm (1.63 in) |
| Weight | 300 grams (10.5 ounces) typical |
| Country of Origin | U.S.A. |
| Connector Pin / Terminal | Function |
|---|---|
| Terminal A | Positive Signal Out (Signal goes positive with respect to B when case velocity moves toward connector) |
| Terminal B | Negative Signal Return |
Does the 9200-06-05-10-00 require an external power supply to operate?
No, this transducer leverages a moving-coil architecture which inherently creates its own voltage signal output proportional to the vibration velocity without external power.
What is the minimum operating frequency threshold for this precise configuration?
This specific unit uses the -06 option, which defines a minimum operating frequency threshold of 10 Hz (600 cpm).
How should the sensor signal cable be handled over long distances?
The system supports up to 305 meters of leadwire between the velocity sensor and a 3300 or 3500 series monitor, though you should consult the manual for high-frequency roll-off parameters when using extended lengths.
What are the primary differences between this moving-coil sensor and solid-state alternatives?
Moving-coil sensors display much lower sensitivity to impact or impulsive excitations compared to embedded integration solid-state alternatives, providing specific advantages on designated casing installations.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 9200-06-05-10-00
Country of origin:United States
Product Type: Velocity Seismoprobe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 420g
Dimensions: 10.2cm x 4cm x 4cm
Shipping port: Xiamen
Warranty: 12 months
