Description

The Bently Nevada 9571-33 is a heavy-duty shielded interconnect cable assembly designed to route operational data measurements between machinery transducers and central monitoring systems. This specialized link asset features a 33-foot (10-meter) pre-cut measurement layout built with 0.382 mm2 (22 AWG) internal wire conductors. To preserve field loop integrity within wet or aggressive unconditioned operational locations, the assembly is outfitted with a factory-molded, moisture-resistant female connector at the transducer termination interface, paired with secure ring lugs on the monitor termination side. It provides stable electrical shielding constraints to mitigate high-frequency ground path loop disruptions, helping maintain uncompromised monitoring infrastructure tracking performance over an extended industrial thermal span.

Features

• Fabricated using robust internal 0.382 mm2 (22 AWG) shielded cabling paths.
• Factory-terminated with a moisture-resistant female plug on the field transducer end.
• Pre-outfitted with industrial ring lugs on the control chassis terminal end.
• Engineered to preserve signaling pathways from harsh external electrical field emissions.

Applications

• High-integrity dynamic signal routing from field-installed machinery transducers to central machinery protection monitors.
• Harsh unconditioned process areas requiring specialized moisture-protected connectivity harnesses.
• Industrial rotating machinery assets demanding continuous, low-noise sensor signal loop integration.

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Lay out the 33-foot cable run along designated industrial cable trays, keeping the entire path clear of extreme physical compression zones or high-friction edges.
• Align and couple the moisture-resistant female terminal interface completely onto the transducer thread pin array until the environmental seat is achieved.
• Secure the ring lug terminations firmly to the monitoring chassis block terminals, ensuring adequate screw tension to prevent vibrational loop interruptions.
• Separate the sensor communication trajectory from high-voltage primary motor power lines to prevent field noise coupling or transient signal interference.
