The 990-10-XX-01-00 (Internal SKU/Part Number: 283278-01) is an industrial, loop-powered 990 Vibration Transmitter engineered by Bently Nevada (a Baker Hughes business). This specialized device provides continuous machinery condition monitoring and asset protection by interfacing field transducers directly with plant automation systems. It integrates the high-frequency signal conditioning electronics of a proximity sensor and an analog transmitter into a single, compact polycarbonate housing. The unit accepts inputs from a non-contacting 3300 XL 8mm eddy-current proximity probe and extension cable system, converting raw shaft micro-gap variations into a linear, proportional 4 to 20 mA analog current loop output. This configuration enables plant operators to route critical radial vibration data straight to Distributed Control Systems (DCS) or Programmable Logic Controllers (PLC) without the added infrastructure of a separate, rack-based monitor chassis.
This exact hardware configuration features an expanded factory-calibrated full-scale measurement scale of 0-10 mils pp (0-250 um pp), designed for machines with larger expected rotor vibration amplitudes. The unit is equipped with integrated 35 mm DIN rail clips for rapid, toolless snap-on installation into local marshalling junction boxes. The agency option is designated as -00, which represents the standard, non-hazardous area base model for general-purpose plant zones. The internal tracking number 283278-01 represents the modern OEM manufacturing assembly designation, incorporating high-stability surface-mount components and enhanced RFI/EMI noise suppression filters over legacy iterations while maintaining identical physical and electrical drop-in backward compatibility.
| Option Code Slot | Selected Option Value | Technical Detail |
|---|---|---|
| Model Number | 990 | 990 Vibration Transmitter Product Family |
| A: Full-scale Option | -10 | 0-10 mils peak-to-peak (0-250 um peak-to-peak) measurement scale |
| B: System Length Option | -XX | Configurable system loop length (Matches probe/cable design parameters) |
| C: Mounting Option | -01 | 35 mm DIN rail clips factory-installed |
| D: Agency Approval | -00 | None (Standard safety area classification for non-hazardous zones) |
| Internal Assembly Part ID | 283278-01 | Modern factory production assembly code |
| Parameter | Detail |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Ordering Code | 990-10-XX-01-00 |
| OEM Assembly Part ID | 283278-01 |
| Product Type | Two-Wire Proximity Vibration Transmitter |
| Full Scale Linear Calibration | 0 to 10 mils pp (0 to 250 um pp) peak-to-peak displacement |
| Output Loop Signaling | Proportional 4 to 20 mAdc current loop |
| Buffered Output Scale Factor | Nominal 7.87 V/mm (200 mV/mil) corresponding to raw probe gap voltage |
| Buffered Output Impedance | 10 kohm nominal (Protected against continuous short circuit faults) |
| Supply Voltage Range | +12 Vdc to +35 Vdc loop power required at the terminal links |
| Transducer Core Matching | Calibrated for standard 3300 XL 8mm proximity probe and extension cable loops |
| Field Wiring Block Capacity | Terminal strip accepting wire cross-sections up to 1.5 mm squares (16 to 24 AWG) |
| Enclosure Construction Material | Polycarbonate body structure integrated with an aluminum base plate |
| Net Component Weight | 0.43 kg (0.9 lbm) |
| Operating Temperature Bounds | -35 degC to +85 degC |
| Storage Temperature Bounds | -51 degC to +100 degC |
| Relative Humidity Index | 95% maximum, non-condensing atmosphere constraints |
| Interface Element | Function Assignment |
|---|---|
| PROBE Coaxial Port | Miniature coaxial connection point receiving the incoming transducer extension cable |
| + (SIG) Terminal | Positive current loop connection receiving incoming +12 to +35 Vdc loop power inputs |
| - (COM) Terminal | Negative current loop connection returning the regulated 4 to 20 mA measurement signal |
| BUF BNC Port | Front-panel isolated BNC socket providing unconditioned sensor voltage waves |
