The CP2E-N30DT1-D is a high-performance Programmable Controller from Omron’s CP2E series, designed for versatile and reliable industrial machine control. This compact CPU unit features a total of 30 I/O points, comprising 18 digital inputs and 12 digital outputs. The outputs are of the sourcing transistor type, making them ideal for high-speed switching applications and integration with PNP-configured field devices. Operating on a 24 VDC power supply, the controller is optimized for space-constrained installations while providing advanced connectivity and processing capabilities typical of the modern Omron micro-PLC lineup.

Features

• 30 I/O points (18 Inputs / 12 Outputs)
• Sourcing transistor output type for high-speed switching
• Standardized 24 VDC supply voltage
• Compact, integrated CPU unit design
• Efficient power consumption profile
• Suitable for diverse automation tasks from packaging to material handling

Technical Specifications

Installation Guidelines

• Mounting: Install the CP2E-N30DT1-D on a standard 35 mm DIN rail inside a control cabinet. Ensure adequate clearance for cable management and heat dissipation.
• Wiring: * Inputs: Connect sensors to the 18 input terminals. Ensure correct common voltage levels.
  • Outputs: The transistor (sourcing) outputs provide current to the load. Verify that the load voltage and current requirements are compatible with the output specifications to avoid module damage.
• Powering: Provide a stable 24 VDC power supply. Use separate power circuits for the controller and high-power actuators to minimize electrical noise.
• Grounding: Connect the functional earth terminal to the cabinet’s main ground to maintain electromagnetic compatibility and ensure system stability.
