The 060G2115 is a high-precision AKS 33 Pressure Transmitter from Danfoss, specifically developed for the refrigeration and air conditioning industry. This sensor provides reliable pressure measurement using a 4–20 mA output signal and is engineered to function across a wide range of environmental and medium temperatures. Its robust IP65-rated enclosure and sealed gauge reference ensure consistent performance even in challenging industrial refrigeration applications.

Features

• Optimized for refrigeration and air conditioning systems
• Sealed gauge pressure reference for precise measurement consistency
• Standard 4–20 mA current output for easy PLC/DCS integration
• Wide operational temperature range: -40 degC to 85 degC
• Durable IP65 enclosure rating protecting against dust and moisture
• Standard EN 175301-803-A electrical connection

Technical Specifications

Installation Guidelines

• Mounting: Install the transmitter in an area where the pressure pulses are dampened. For refrigeration systems, mount the sensor in a position that prevents oil from settling in the pressure port.
• Orientation: While the device is robust, mounting it vertically with the electrical connection facing upward or sideways is recommended to prevent moisture accumulation in the connector.
• Wiring: Use high-quality shielded twisted-pair cables for the 4–20 mA signal. Connect the shield to the common ground at the controller end only to avoid ground loops.
• Sealing: Ensure the connector gasket is properly seated before tightening the angular connector to maintain the IP65 rating.
• Calibration: Ensure the controller input matches the 4–20 mA range of the transmitter to avoid measurement offsets.
