Danfoss 132F0005 FC-051P1K5S2E20H3BXCXXXSXXX VLT Micro Drive

SKU 132F0005

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Danfoss
Product No.: 132F0005
Origin United States
Product Type: Frequency Converters
Payment: T/T, Western Union
Weight: 5.0 kg
Dimensions: 16.8 cm x 7.5 cm x 17.6 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

The 132F0005 is a compact FC-051P1K5S2E20H3BXCXXXSXXX VLT Micro Drive optimized for reliable motor control in space-constrained industrial environments. Part of the Danfoss VLT Micro Drive series, this model is designed for 1.5 kW (2.0 HP) single-phase motor applications operating on 200–240 VAC. It features an IP20-rated chassis and includes an integrated brake chopper, making it well-suited for applications requiring controlled deceleration or stop sequences.

Features

Integrated brake chopper for dynamic braking requirements
RFI Class A1/B (C1) filter ensures electromagnetic compatibility
Conformal coated PCB for increased environmental resistance and longevity
High operational flexibility with 5 programmable digital inputs and 2 analogue inputs
Supports both VVC+ (up to 200 Hz) and U/f (up to 400 Hz) motor control modes
Compact, user-friendly design for efficient cabinet installation

Applications

Small conveyors and material handling belts
Centrifugal pumps and aeration fans
Industrial agitators and mixers
Packaging machines
General speed control for small machinery

Technical Specifications

Feature	Specification
Manufacturer	Danfoss
Product Number	132F0005
Model	FC-051P1K5S2E20H3BXCXXXSXXX
Product Group	VLT Micro Drive FC 51
Power Rating	1.5 kW / 2.0 HP
Input Voltage	200–240 VAC (Single Phase)
Output Frequency	0–200 Hz (VVC+), 0–400 Hz (U/f)
Enclosure	IP20 / Chassis
RFI Filter	Class A1/B (C1)
Digital Inputs	5 (0–24 VDC)
Analogue Inputs	2
Dimensions (L x W x H)	16.8 cm x 7.5 cm x 17.6 cm
Shipping Weight	5 Kg

Installation Guidelines

Mounting: Mount the drive vertically to allow the cooling air to flow unobstructed through the heat sink.
Ventilation: Maintain minimum clearances above and below the device as specified in the manual to ensure adequate thermal dissipation.
Wiring: Keep control signal cables and power cables separate to minimize cross-talk and electromagnetic interference. Use shielded cables for all I/O connections.
Grounding: Connect the drive chassis to the system ground (PE) to ensure safety and effective RFI filtering.
Environment: Ensure the drive is installed in a clean environment, protected from oil mist, aggressive vapors, and conductive dust.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What power rating is the 132F0005 designed for?

The 132F0005 is rated for 1.5 kW (2.0 HP) motors.

Does this drive support single-phase input?

Yes, this model is designed for 200–240 VAC single-phase power supply.

Does the unit have a built-in brake chopper?

Yes, it features an integrated brake chopper to manage braking energy.

What is the maximum output frequency in U/f mode?

In U/f control mode, the drive supports an output frequency of up to 400 Hz.
