GE IS200WEORG1A Mark VIe Speedtronic Wind Turbine Output Board

SKU IS200WEORG1A

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: General Electric
  • Product No.: IS200WEORG1A
  • Origin United States
  • Product Type: Wind Turbine Board
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.38 kg
  • Dimensions: 28cm x 12.6cm x 3.5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Mark VIe Wind Turbine Board
Quantità
Call sales Contact

Product Description

Description

The IS200WEORG1A is a specialized wind turbine output board designed by GE Energy for integration within the Mark VIe Speedtronic turbine control platform. Operating explicitly as an output and power transfer assembly within wind turbine drive systems, this component distributes local signal paths and conditions auxiliary power lines. The IS200WEORG1A features integrated high-voltage overcurrent protection circuits, heavy-duty filtering components, and clear component designation layout structures to interface directly with wind turbine drive operations.

Features

  • High-Temperature Filtering Subsystem: Equipped with two Nichicon 270uF 150 Celsius electrolytic capacitors to maintain electrical line stability in high-temperature environments.
  • Overvoltage Transient Protection: Includes an orange-coated 3kV single-layer ceramic capacitor positioned near the primary filter elements to buffer voltage spikes.
  • Dual-Tier Overcurrent Protection: Populated with five heavy-duty circuit protection fuses, divided between 250V rated lines and 3 dedicated 600V protection circuits.
  • Precision Power Transfer Balancing: Integrates onboard transformers engineered to safely isolate and transfer power lines to auxiliary system boards.
  • Onboard Jumper Control: Features accessible jumper links labeled J4 and J5 to allow tailored circuit configurations by the system field engineer.

Applications

  • Mark VIe Wind turbine drive assembly monitoring
  • Power distribution and output isolation networks within alternative energy setups
  • Auxiliary power routing and control cabinets

Technical Specifications

Item Description / Value
Manufacturer GE Energy
Series Mark VIe Speedtronic
Part Number IS200WEORG1A
Functional Acronym WEOR
Functional Description GE Printed Circuit Board
PCB Coating Normal Coating
Functional Revision 1 A
High-Current Resistor Specifications 100 Ohm (Resistors 1, 2, 3, 5, 8, and 9)
Total Resistors 15 total
High-Temperature Capacitors (C1, C3) Nichicon 270uF, 150 Celsius
Surge Capacitor (C2) 3kV Single Layer Ceramic
Maximum Source Supply Label FROM 230L-N SOURCE 250VA MAX

Installation Guidelines

  • Crimp Clearance Standards: Maintain the specified factory crimp clearances between the high-power resistors (R1, R2, R3, R5, R9) and the underlying circuit surface to ensure heat dissipation and electrical isolation.
  • Chassis Attachment: Utilize the 5 factory-drilled mounting holes along the board framework to securely anchor the unit onto the enclosure panel plate.
  • Handling Protocols: Always discharge static build-up and utilize an ESD-safe matting surface before manipulating configuration jumpers J4 or J5.
