The GE Multilin UR-6EH is a high-reliability hardware component within the Universal Relays (UR) series, engineered to provide standalone contact inputs and contact outputs for substation automation and power system protection. This specific module incorporates a 6E order configuration, which delivers 4 Form-C relay outputs and 8 standalone digital contact inputs directly into the primary protection chassis. Operating as a critical link for intersystem signaling, the GE Multilin UR-6EH enables continuous status monitoring and protective device command routing, facilitating bidirectional control transmission between the main protective relay and surrounding critical substation assets like circuit breakers, disconnect switches, and ancillary control loops.
| Suffix Code | Description |
|---|---|
| 6E | 4 Form-C Outputs, 8 Digital Inputs |
| H | Standard/Hi-Voltage Hardware Interface Suffix |
| Parameter | Specification |
|---|---|
| Manufacturer | GE Multilin |
| Manufacturing Location | Ontario, Canada |
| Module Series Type | Universal Relays (UR) Series Platform |
| Configuration Code | 6E (4 Form-C Outputs / 8 Digital Inputs) |
| Output Contact Format | SPDT (Single Pole-Double Throw) |
| Configuration Interface Software | EnerVista |
| Hardware Variant Suffix | H |
| Approximate Weight | 2.55 lbs |
Slide the module directly into its designated slot housing on the rear panel of the Universal Relay chassis structure. Ensure the card locks firmly into the internal backplane connectivity rail before tightening any exterior locking screws.
Route all digital signal cables away from primary high-voltage busways or current transformer secondary cables. Utilize integrated mechanical anchors to apply appropriate strain relief, guarding individual terminal interfaces against intense mechanical stress.
Execute all wiring actions according to the point definitions outlined in the official Universal Relays instruction manuals. Ring-tongue or spade terminal lugs are recommended on all screw-terminal contact blocks to avoid intermittent conductor displacement.
Maintain strict shield termination integrity for all external digital control links. Connect any cable shield lines to the nearest dedicated substation chassis earth ground point to protect input signal validity against inductive switching fields.
Global Express Shipping
Returns & Warranty
Manufacturer: General Electric
Product No.: UR-6EH
Country of origin:Canada
Product Type: Digital I/O Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 500g
Dimensions: 16.3cm x 4.2cm x 21cm
Shipping port: Xiamen
Warranty: 12 months
