General Electric IS220YDOAS1AJ Mark VIe Discrete Output Pack

SKU IS220YDOAS1AJ

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: General Electric
  • Product No.: IS220YDOAS1AJ
  • Origin United States
  • Product Type: Discrete Output Pack
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.36 kg
  • Dimensions: 45 mm x 120 mm x 155 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Discrete Output Pack Mark VIe
Quantità
Call sales Contact

Product Description

Description

The IS220YDOAS1AJ is a discrete output pack engineered for the Mark VIe series control platforms. This device forms an electrical interface linking one or two redundant I/O Ethernet networks directly to a discrete output terminal board. It runs dedicated firmware to regulate up to twelve external potential relays while processing real-time relay and fuse feedback monitoring tracking loops. Equipped with an internal acquisition board and a specialized BPPB common processor board, the hardware uses a DC-37 pin connection system to drive terminal components. The control system supports flexible hardware redundancy profiles, including three modules for Triple Modular Redundant (TMR) voting applications or a single module for simplex configurations, managing diagnostic checks via voting disagreement algorithms.

Features

  • Provides electrical control interface functions between I/O dual Ethernet networks and external discrete output hardware.
  • Drives up to twelve potential relays with dedicated relay and fuse feedback diagnostic monitoring loops.
  • Utilizes a specialized voting disagreement methodology with enablement configurations to pinpoint network faults.
  • Runs internal automated self-diagnostic cycles upon initialization to check flash memory, processor board circuits, RAM, and active dual Ethernet ports.

Applications

  • Mark VIe Distributed Control Systems: Driving field relays and handling discrete control sequencing across turbine automation nodes.
  • TMR Redundant Control Loops: Providing synchronized tri-modular processing for high-availability industrial systems.
  • Simplex Output Interfaces: Direct discrete terminal board switching setups inside non-redundant utility panels.

Technical Specifications

Parameter Value
Manufacturer GE Energy
Part Number IS220YDOAS1A (Pack Model: IS220YDOAS1AJ)
Product Type Discrete Output Pack
Series Mark VIe
Functional Acronym / Abbreviation YDOA
Components Acquisition and Common Processor Board
Processor Board Type BPPB
Type of I/O Relay and Fuse Feedback
ControlST Software Suite Versions Supports V06.01 and Later Versions
Firmware V05.00 and Later
Delta Method Voting Disagreement and Diagnostic Enable/Disable
Manuals GEH-6725, Vol I and II
Ambient Temperature Range -30 to + 65 Celsius
Shipping Weight 0.8 lb (0.36 KG)
Estimated Dimensions (W x H x D) 45 mm x 120 mm x 155 mm



Connections/Interfaces

Connector Pin Function
DC-37 Pin Connector Direct interface to the associated discrete output terminal board
Ethernet Ports Connection to one or two I/O Ethernet networks



Installation Guidelines

  • Disconnect all control power lines before fitting the discrete output hardware to the terminal base block.
  • Secure the DC-37 pin connection point tightly to maintain error-free electrical path linking to the field relays.
  • Configure the correct application architecture within the ControlST Software Suite (Simplex or TMR) before online deployment.
  • Ensure adequate ventilation spacing to maintain the ambient operating thermal metrics between -30 and + 65 Celsius.
