Honeywell 51405046-175 C300 Controller Module

SKU 51405046-175

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: 51405046-175
  • Origin United States
  • Product Type: DCS Controller Modules
  • Payment: T/T, Western Union
  • Weight: 0.5 kg
  • Dimensions: 235 mm x 180 mm x 65 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

DCS Controller Modules Experion
Quantità
Call sales Contact

Product Description

Description

Designed to serve as the primary execution engine for Honeywell Experion PKS environments, the Honeywell 51405046-175 board assembly delivers deterministic, high-integrity control for complex industrial operations. This printed wiring assembly (PWA) forms the core hardware of the CC-PCNT01 controller module, executing process control strategies, batch recipes, and advanced regulatory control algorithms. Operating on the robust Honeywell C300 platform, it integrates natively with Fault Tolerant Ethernet (FTE) architectures to guarantee uninterrupted control loop execution and seamless supervisory communication.

Features

  • Deterministic Control Execution: Executes continuous control, batch sequencing, and logic operations with highly repeatable cycle times.
  • FTE Redundancy Integration: Works in conjunction with the host Input Output Termination Assembly (IOTA) to establish redundant communication paths, eliminating single points of network failure.
  • Experion PKS Integration: Provides direct synchronization with Honeywell Control Builder and Experion Operator Stations without the need for protocol translation gateways.
  • Non-Volatile Memory Backup: Retains active control strategies and system configurations during sudden power loss events.

Applications

  • Petrochemical and refining control networks requiring high-availability DCS architectures.
  • Power generation plant regulatory and auxiliary process controls.
  • Continuous process manufacturing facilities utilizing Honeywell Experion PKS R300 through R500+ systems.

Technical Specifications

Manufacturer Honeywell
PWA Part Number 51405046-175
Associated Module Model CC-PCNT01
Platform Series Experion C300 Control Series
Input Supply Voltage 24V DC (nominal, supplied via IOTA baseplate)
Network Interface Dual Fault Tolerant Ethernet (FTE) via IOTA
Operating Temperature Range 0 to 60 degC
Relative Humidity 5% to 95% RH (non-condensing)
Country of Origin United States
Shipping Weight (Calculated) 2.0 kg
Package Dimensions (Calculated) 235 mm x 180 mm x 65 mm

Connections and Interfaces

Connection / Port Function / Circuit Assignment
Rear Multi-Pin Connector Mates directly to the C300 IOTA (Input Output Termination Assembly) for power, network, and auxiliary bus lines.
FTE Yellow / FTE Green Ports Routed via IOTA to control network switches for high-speed redundant communication.

Empirical Engineering Insights

Alternative Models & Compatibility

The board revision 51405046-175 functions as the internal PWA of the complete CC-PCNT01 Honeywell controller block. It is backward compatible with earlier Honeywell IOTA chassis configurations designed for the CC-PCNT01 module. Ensure your Experion PKS system release is fully compatible with the firmware revision flashed on this unit; mismatched firmware between active and standby C300 modules will prevent proper redundancy synchronization.

Application Pitfalls & Engineering Notes

To prevent thermal accumulation in densely populated control cabinets, standard orientation must be vertical on the mounting panel. In enclosed non-ventilated cabinets, keep a minimum of 50mm clearance above and below the module to maintain convective airflow and avoid hardware failures related to components exceeding the 60 degC operating threshold.

Commissioning & Wiring Tips

When configuring the network nodes inside Honeywell Control Builder, verify that the active FTE ports map directly to dedicated, non-overlapping subnet routes. Always ensure the shielding drain wire of the main 24V DC power feed is securely tied to the single-point cabinet ground on the IOTA chassis to shield the internal processor from high-frequency transient noise.

Installation Guidelines

CRITICAL WARNING: De-energize all primary 24V DC supply lines to the IOTA baseplate before mounting or extracting the 51405046-175 module. Performing hot-swaps on a system with unstable or misconfigured grounding can cause electrical arcing, damage the multi-pin connector contacts, or lead to unexpected process shutdowns.
1
Inspect the multi-pin backplane mating connector on both the IOTA and the 51405046-175 module for debris, bent pins, or mechanical damage.
2
Align the guide pins on the module base with the corresponding holes on the IOTA plate. Gently push the module home until it is fully seated.
3
Secure the retaining fasteners on the controller housing to ground the module chassis and prevent dislodging under high vibration conditions.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the relationship between part number 51405046-175 and model CC-PCNT01?
The 51405046-175 is the internal Printed Wiring Assembly (PWA) board revision. When housed in its plastic assembly shell, it constitutes the CC-PCNT01 C300 Controller Module.
Does this C300 module support redundant operating modes?
Yes, C300 controllers support full redundancy when paired with an identical module on a redundant IOTA board and configured within Honeywell Experion PKS Control Builder.
What happens if there is a firmware mismatch between active and backup units?
A firmware mismatch will prevent database synchronization, meaning the secondary controller will fail to take over the control loop in the event of an active controller failure.
What power input is required to operate this PWA?
The board operates on 24V DC nominal power supplied directly through the multi-pin connector from the host IOTA backplane.
