Honeywell CC-C8DS01 Experion Series C Cabinet Door Switch Assembly

SKU CC-C8DS01

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Honeywell
Product No.: CC-C8DS01
Origin United States
Product Type: Cabinet Door Switches
Payment: T/T, Western Union
Weight: 2.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Monitoring enclosure integrity and physical access parameters, the Honeywell CC-C8DS01 functions as a dedicated cabinet door switch assembly engineered for integrated deployment within Experion Series C control systems. This industrial-grade assembly is designed specifically for direct mechanical compatibility with Rittal TS8 Series C Cabinet frames, ensuring precise open/closed state monitoring. By facilitating automated diagnostic feedback, the CC-C8DS01 enables plant personnel to track cabinet access, trigger internal enclosure illumination, manage cooling fan operation, and generate system-level security alarms through the Experion platform.

Features

Engineered Fit: Custom mounting brackets align seamlessly with standard Rittal TS8 structural frame profiles without requiring field modifications.
Heavy-Duty Actuation: Designed to withstand repeated mechanical cycles typical of high-traffic marshalling and system cabinet doors.
Dual-State Integration: Provides clean contact transitions directly to system controllers or power distribution assemblies for immediate status reporting.
Low Profile Design: Minimizes protrusion into the cabinet interior, preserving space for high-density Series C I/O modules and cabling.

Applications

Distributed Control System (DCS) main marshalling enclosures.
Experion Series C field termination assembly (FTA) cabinets.
Industrial safety system (SIS) enclosures demanding physical access logging.
Power distribution cabinets within high-vibration or extreme-temperature control rooms.

Technical Specifications

Parameter	Specification Value
Manufacturer	Honeywell
Model Number	CC-C8DS01
Compatible Enclosure System	Rittal TS8 Series C Cabinets
Function	Cabinet Door Switch / Access Monitoring
Contact Configuration	Dry Contact (typically SPDT/DPST standard interface)
Shipping Weight (Calculated)	2.0 kg (including bracket, wiring, and hardware)

Empirical Engineering Insights

Alternative Models & Compatibility

The CC-C8DS01 is standard hardware across Honeywell Experion PKS Series C cabinets utilizing the Rittal TS8 format. If retrofitting older or customized non-Rittal enclosures, custom mechanical adapter plates may be required to maintain correct switch alignment with the door edge profile.

Application Pitfalls & Engineering Notes

Over time, heavy cabinet doors can settle slightly due to thermal cycling or structural shifting of the mounting floor. Ensure that the switch plunger is regularly verified for physical contact alignment to prevent spurious "Door Open" alarms at the DCS console, which can block remote configuration updates if safety interlocks are tied to cabinet status.

Commissioning & Wiring Tips

When wiring the switch to the Experion Series C power distribution or I/O subsystem, ensure that the cabling is run through appropriate flexible conduit or bundled inside the structural frame channels. Avoid routing switch wires adjacent to high-voltage AC mains supply lines within the cabinet to prevent capacitive noise coupling into the low-voltage monitoring circuits.

Installation Guidelines

CRITICAL WARNING

Isolate all electrical power utilities and lock out/tag out (LOTO) all internal cabinet power sources, auxiliary fans, and remote power distribution lines before initiating the mechanical installation. Verify zero voltage present inside the immediate installation area prior to handling switch terminals or bracket mounting paths.

Position the CC-C8DS01 mounting bracket on the inner channel of the Rittal TS8 door frame profile, ensuring correct height alignment with the corresponding door actuator tab.

Secure the bracket using the provided self-tapping mounting screws. Torque to manufacturer recommendations to avoid striping the frame channels.

Route the contact wiring through the designated vertical cable management rails, securing it with non-conductive cable ties to prevent interference with door hinges.

Perform a continuity check across the switch contacts by manually operating the door. Verify correct electrical state change before restoring cabinet auxiliary utility power.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the Honeywell CC-C8DS01 in Experion systems?

It serves as a cabinet door monitoring switch, providing real-time door open/closed feedback to the Experion control system for security, diagnostics, or environmental control.

Which cabinet frames are compatible with this switch assembly?

The CC-C8DS01 is specifically designed for integration with standard Rittal TS8 Series C industrial enclosures used in Honeywell Experion PKS configurations.

Does the CC-C8DS01 assembly include mounting brackets?

Yes, the assembly is supplied with a custom-engineered mounting bracket that fits directly onto the vertical or horizontal frame profiles of a TS8 enclosure.

How should the switch be wired for alarm systems?

It should be wired to a dedicated digital input or a system power monitoring block using low-voltage dry contact wiring, keeping it shielded from high-power AC cables.
