Honeywell CC-TAOX01 51308351-175 IOTA di uscita analogica Experion PKS

SKU CC-TAOX01 51308351-175

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: CC-TAOX01 51308351-175
  • Origin United States
  • Product Type: IOTA di uscita analogica
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.35 kg
  • Dimensions: 300 mm x 120 mm x 60 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Analog Output Modules

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell CC-TAOX01 51308351-175 IOTA di uscita analogica Experion PKS

Download Open in new tab
Quantità
Call sales Contact

Product Description

The Honeywell CC-TAOX01 is a non-redundant Analog Output Input Output Termination Assembly (IOTA) used within the Experion PKS Series C I/O system. It serves as the physical interface layer for mounting a Series C Analog Output module, connecting field device wiring directly to the I/O electronics and facilitating communication with C300 controllers over the Series C I/O Link.

Designed for compact control cabinet layouts, the board features an integrated, tilted mounting footprint that eliminates the need for separate field termination assembly (FTA) cables. The CC-TAOX01 provides 16-channel field connections, on-board fusing for loop protection, and non-incendive power distribution for 4-20 mA field loops without requiring external marshalling.

Features

  • Direct Module Interface: Mounts single Series C Analog Output I/O Modules (IOM) directly onto the assembly, saving panel space and eliminating FTA cables.
  • Integrated Fusing: Includes dedicated on-board field wiring protection fuses for output safety.
  • Non-Incendive Field Power: Supports 4-20 mA current loops with integrated loop power distribution without requiring external field marshalling.
  • Standard Screw Terminals: Features onboard screw terminal blocks for direct field wiring connections.
  • Series C Architecture: Integrates directly into the Experion PKS Series C I/O Link topology.

Applications

  • Distributed Control Systems (DCS) process automation in Experion PKS C300 environments.
  • Continuous control loops utilizing 4-20 mA analog actuators, control valves, and field indicators.
  • Standard and non-incendive field wiring loop installations.

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model CC-TAOX01
Product Type Analog Output IOTA (Non-redundant)
System Compatibility Experion PKS Series C I/O
Compatible Modules CC-PAOH01, CC-PAOX01
Number of Channels 16
Field Signal Type 4-20 mA
Redundant Capability Non-redundant
On-Board Fuse F1 Fuse (Fusing for field power/module protection)

Connections/Interfaces

Connector Pin Function
Terminal 1 Channel 1 Output (+) / Signal
Terminal 2 Channel 1 Return (-) / Common
Terminal 3 Channel 2 Output (+) / Signal
Terminal 4 Channel 2 Return (-) / Common
Terminals 5–32 Channels 3 through 16 Output (+) and Return (-) Assignments
Power Screw/Bus 24V DC System Power Input & Common Ground Connection

Installation Guidelines

  • Mounting: Securely attach the CC-TAOX01 IOTA horizontally or vertically onto the Series C carrier assembly inside the cabinet prior to attaching the IOM.
  • Module Attachment: Align and seat the Series C Analog Output Module (CC-PAOH01 or CC-PAOX01) onto the IOTA card connectors until fully engaged.
  • Grounding: Ensure cabinet safety ground and signal common ground are firmly wired to the IOTA grounding studs in accordance with system design guidelines.
  • Fusing Maintenance: Verify the F1 fuse rating on the board prior to energizing connected 24V field circuits.
  • Wiring Practice: Route field signal lines away from high-voltage cables to minimize noise and EMI/RFI interference.
