Honeywell MU-TAOY22 51204172-125 TotalPlant Solution Analog Output FTA

SKU MU-TAOY22 51204172-125

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: MU-TAOY22 51204172-125
  • Origin United States
  • Product Type: Analog Output FTA
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.45 kg
  • Dimensions: 125 mm x 120 mm x 60 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Analog Output FTA TPS

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell MU-TAOY22 51204172-125 TotalPlant Solution Analog Output FTA

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Honeywell MU-TAOY22 (Part Number 51204172-125) is an Analog Output Field Termination Assembly (FTA) designed for integration within the TotalPlant Solution (TPS) Process Manager (PM) and Advanced Process Manager (APM) I/O subsystems. The device operates as an interface between the Process Manager I/O Processors (IOP) and field instrumentation, transmitting 4 to 20 mA analog control signals to field devices such as control valves, actuators, and positioners. Built with microprocessor-controlled diagnostic support and redundant cabling connections, the MU-TAOY22 51204172-125 provides steady signal routing and continuous field loop health monitoring for industrial process automation environments.

Features

  • High-density analog output signal distribution for field actuators and positioners
  • Compatible with Honeywell High Level Analog Output (HLAO) and Analog Output (AO) I/O Processors
  • Dual redundant interface connectors for redundant field bus cabling configurations
  • DIN rail mounting form factor for standardized control cabinet installation
  • Microprocessor-supported loop continuity and diagnostic monitoring

Applications

  • Distributed Control Systems (DCS) process automation
  • Chemical processing plants and refineries
  • Power generation facility control loops
  • Water and wastewater treatment automation
  • Continuous process control applications requiring 4-20 mA loop interfaces

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model MU-TAOY22
Part Number 51204172-125
Product Type Field Termination Assembly (FTA)
System Compatibility TPS Process Manager (PM) / APM
Signal Type Analog Output (4-20 mA)
I/O Module Compatibility High Level Analog Output (HLAO) / AO Processors
Mounting Configuration DIN Rail / Channel Mount
Operating Temperature Range 0 degC to 60 degC
Storage Temperature Range -40 degC to 85 degC
Relative Humidity Range 5% to 95% non-condensing

Installation Guidelines

  • Mounting: Securely mount the assembly onto standard 35 mm DIN rail or channel carrier within a shielded control enclosure.
  • Grounding: Connect the field shield terminals directly to the dedicated instrument ground bus to minimize noise interference.
  • Shielding: Ensure all field signal cabling utilizes twisted-pair shielded conductors with single-point grounding at the cabinet end.
  • Cable Routing: Maintain physical separation between high-voltage power lines and low-voltage analog signal cables to mitigate EMI/RFI impact.
  • Wiring Termination: Tighten terminal block screws according to standard cabinet installation torque requirements to prevent signal loss or floating connections.
