Providing precise analog voltage distribution within integrated control systems, the Honeywell TC-0AV081 serves as a high-density, 8-channel analog output module designed specifically for the Logix 5000 platform. This Honeywell-badged module is fully compatible with standard chassis architectures, enabling seamless integration into DCS and industrial automation systems. It translates digital control variables from the controller memory into highly accurate analog voltage signals to drive control valves, actuators, and speed reference inputs on variable frequency drives.
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model / Article Number | TC-0AV081 |
| Series Platform | Logix 5000 / Experion |
| Module Type | Analog Output (Voltage) |
| Number of Channels | 8 Channels |
| Output Voltage Range | -10 V to +10 V DC (Typical configuration) |
| Backplane Slot Width | Single slot (1 slot) |
| Weight | 1.8 kg |
| Shipping Weight (Calculated) | 2.8 kg |
The Honeywell TC-0AV081 is functional-equivalent to standard Allen-Bradley ControlLogix 1756 voltage output modules. However, in Honeywell Experion PKS configurations, you must ensure the system's firmware package includes the correct Honeywell hardware definitions to recognize the TC-0AV081 identity code properly during chassis discovery.
When utilizing voltage outputs over long distances, line resistance drop can alter the signal level received at the actuator. If your wiring paths exceed 100 meters, monitor for voltage attenuation and compensate within your controller scaling or transition to isolated current loop converters where applicable to maintain precise positioning accuracy.
For clean signals free of electromagnetic noise, use individually shielded twisted-pair cabling for each voltage channel. The shield must be connected to a clean instrument ground point strictly at the chassis end of the cable run; leaving the shield floating or grounding both ends can generate ground loops that distort your analog output values.
Ensure that all external field-side voltage loops are completely de-energized and verified with a calibrated multimeter before attaching or removing the field wiring terminal block. Although the module support RIUP backplane communication, hot-wiring active high-energy analog loops can damage delicate on-board digital-to-analog converters (DACs).
Align the module circuit board with the upper and lower guide rails of the designated slot in the rack.
Slide the module firmly into the chassis until the top and bottom locking tabs audibly click and lock into place.
Attach the pre-wired Removable Terminal Block (RTB) to the front interface, secure the housing screws, and apply field loop power.
Global Express Shipping
Returns & Warranty
Manufacturer: Honeywell
Product No.: TC-0AV081
Country of origin:United States
Product Type: Analog Output Modules
Payment: T/T, Western Union
Weight: 2800g
Shipping port: Xiamen
Warranty: 12 months
Providing precise analog voltage distribution within integrated control systems, the Honeywell TC-0AV081 serves as a high-density, 8-channel analog output module designed specifically for the Logix 5000 platform. This Honeywell-badged module is fully compatible with standard chassis architectures, enabling seamless integration into DCS and industrial automation systems. It translates digital control variables from the controller memory into highly accurate analog voltage signals to drive control valves, actuators, and speed reference inputs on variable frequency drives.
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model / Article Number | TC-0AV081 |
| Series Platform | Logix 5000 / Experion |
| Module Type | Analog Output (Voltage) |
| Number of Channels | 8 Channels |
| Output Voltage Range | -10 V to +10 V DC (Typical configuration) |
| Backplane Slot Width | Single slot (1 slot) |
| Weight | 1.8 kg |
| Shipping Weight (Calculated) | 2.8 kg |
The Honeywell TC-0AV081 is functional-equivalent to standard Allen-Bradley ControlLogix 1756 voltage output modules. However, in Honeywell Experion PKS configurations, you must ensure the system's firmware package includes the correct Honeywell hardware definitions to recognize the TC-0AV081 identity code properly during chassis discovery.
When utilizing voltage outputs over long distances, line resistance drop can alter the signal level received at the actuator. If your wiring paths exceed 100 meters, monitor for voltage attenuation and compensate within your controller scaling or transition to isolated current loop converters where applicable to maintain precise positioning accuracy.
For clean signals free of electromagnetic noise, use individually shielded twisted-pair cabling for each voltage channel. The shield must be connected to a clean instrument ground point strictly at the chassis end of the cable run; leaving the shield floating or grounding both ends can generate ground loops that distort your analog output values.
Ensure that all external field-side voltage loops are completely de-energized and verified with a calibrated multimeter before attaching or removing the field wiring terminal block. Although the module support RIUP backplane communication, hot-wiring active high-energy analog loops can damage delicate on-board digital-to-analog converters (DACs).
Align the module circuit board with the upper and lower guide rails of the designated slot in the rack.
Slide the module firmly into the chassis until the top and bottom locking tabs audibly click and lock into place.
Attach the pre-wired Removable Terminal Block (RTB) to the front interface, secure the housing screws, and apply field loop power.
