TC-FPDXX2

Honeywell

Honeywell TC-FPDXX2 Uncoated Series-A Power Supply

SKU TC-FPDXX2

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: TC-FPDXX2
  • Origin United States
  • Product Type: Power Supply Modules
  • Payment: T/T, Western Union
  • Weight: 1.1 kg
  • Dimensions: 11.2 x 14.5 x 14.0 cm (4.41 x 5.71 x 5.51 in)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Power Supply Modules Series-A

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell TC-FPDXX2 Uncoated Series-A Power Supply

Download Open in new tab
Quantità
Call sales Contact

Product Description

The Honeywell TC-FPDXX2 is an uncoated Series-A non-redundant power supply module designed to deliver reliable DC operating power to modules installed within an Experion LX / Experion LS Chassis Series-A platform. Mounted directly onto the left side of the chassis backplane without consuming an I/O slot, the TC-FPDXX2 converts a nominal 24 VDC input into four regulated backplane output voltages—1.2 VDC, 3.3 VDC, 5.1 VDC, and 24.0 VDC—providing up to 70 W total power output to support controller, network, and I/O module operations.

Features

  • Non-redundant chassis-side mounting designed to power backplane modules without consuming an I/O slot position.
  • Wide DC input range from 19.2 to 32 VDC with tolerance for temporary drops down to 16 VDC during motor starting conditions.
  • Quad-voltage DC backplane output supplying 1.2 VDC, 3.3 VDC, 5.1 VDC, and 24.0 VDC.
  • High total power output capability delivering up to 70 W at 60 degC.
  • Integrated non-replaceable soldered fuse protection for enhanced short-circuit and fire hazard prevention.

Applications

  • Experion LS and C200E process control chassis power distribution.
  • Distributed Control Systems (DCS) operating in 24 VDC plant power environments.
  • Remote I/O chassis assemblies requiring internal backplane logic power.

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model TC-FPDXX2
Coating Uncoated
Input Voltage Range 19.2 to 32 VDC (Input may drop to 16 VDC for max 2 minutes/hour)
Input Power 100 W
Maximum Inrush Current 30 A
Frequency Range DC
Total Power Output Maximum 70 W @ 60 degC
Backplane Output Current, 1.2 VDC 1.5 A
Backplane Output Current, 3.3 VDC 4 A
Backplane Output Current, 5.1 VDC 10 A
Backplane Output Current, 24.0 VDC 2.8 A
Fuse Protection Non-replaceable fuse soldered in place
Wiring Gauge #14 AWG (1.4 mm)
Module Location Left side of chassis (does not consume a slot)
Operating Temperature 0 to 60 degC (32 to 140 degF)
Storage Temperature -40 to 85 degC (-40 to 185 degF)
Operating Humidity 5 to 95% noncondensing
Dimensions (L x D x H) 11.2 x 14.5 x 14.0 cm (4.41 x 5.71 x 5.51 in)
Weight 1.1 kg (2.5 lb.)

Installation Guidelines

  • Mounting Position: Install directly onto the left end of the Series-A chassis backplane. Ensure the power module interlocks properly with the chassis structure.
  • Wiring Requirements: Connect incoming DC power using #14 AWG (1.4 mm) wire to match terminal specifications. Maintain correct input polarity during installation.
  • Power Load Calculation: Calculate total power consumption of all populated backplane modules to ensure combined output power on 1.2 V, 3.3 V, 5.1 V, and 24.0 V rails does not exceed the 70 W limit at 60 degC.
  • Thermal & Clearance: Maintain adequate vertical and horizontal clearance around the chassis assembly to allow proper convective cooling and prevent ambient temperatures from exceeding 60 degC.

Compliance and Certifications

  • UL 508 Industrial Control Equipment
  • Class I, Div 2, Groups A, B, C & D Hazardous and Ordinary locations
  • 89/336/EEC, EMC Directive (EN 50081-2 Emissions, EN 50082-2 Immunity)
  • C-Tick (Australian Radiocommunications Act)
  • CE-Mark Approval
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the power supply module?
The device mounts to the left side of a Series-A chassis to convert 24 VDC input into four regulated backplane voltages, delivering logic power to modules in the rack.
Does installing the power supply take up a chassis slot?
No, the device attaches directly to the left side of the chassis backplane without consuming any standard module slot positions.
What is the total maximum backplane output power available?
The combined power output across all backplane voltage rails must not exceed 70 W at temperatures up to 60 degC.
How is the power supply protected against internal short circuits?
The device contains an internal non-replaceable fuse soldered onto the board to protect against short circuits and fire hazards.
Reviews
