Honeywell TK-PRR021 51309288-475 is a double-wide redundancy module designed for the Experion Chassis Series-A (CIOM-A) platform to support C200 control processor redundancy configurations. Operating within Experion LS and Experion PKS process control architectures, the TK-PRR021 facilitates synchronized, fault-tolerant operation between dual controller chassis.
Equipped with factory-applied conformal coating, Honeywell TK-PRR021 provides corrosion protection in environments rated Moderate (G2) or Harsh (G3) per ANSI/ISA-S71.04-1985 standards. The module occupies two chassis slot positions and draws power directly from internal backplane voltage rails to maintain continuous high availability in industrial process applications.
Conformal coating protection for harsh industrial environments with airborne contaminants
Double-wide form factor occupying two chassis slot positions
Direct backplane integration for C200 control processor redundancy support
Low-power internal backplane draw across 24 VDC, 5 VDC, 3.3 VDC, and 1.2 VDC rails
High-availability DCS and PLC control loops
Redundant C200 control processor systems in Experion PKS and Experion LS platforms
Process automation environments exposed to corrosive atmospheres
| Parameter | Specification |
| Manufacturer | Honeywell |
| Model Number | TK-PRR021 |
| Part / Assembly Number | 51309288-475 |
| Module Type | Redundancy Module (RM) |
| Product Series | Experion Chassis Series-A (CIOM-A) |
| Chassis Slots Required | 2 (Double-wide form factor) |
| Conformal Coating | Yes (TK designation) |
| Backplane Current Draw (24 VDC) | 0.090 A |
| Backplane Current Draw (5 VDC) | 1.000 A |
| Backplane Current Draw (3.3 VDC) | 0.750 A |
| Backplane Current Draw (1.2 VDC) | 0.007 A |
| Operating Temperature | 0 to 60 degC |
| Storage Temperature | -40 to 85 degC |
| Relative Humidity | 5 to 95% noncondensing (derated to 55% above 40 degC) |
| Altitude Range | -300 to +3000 m |
| Vibration (Operating/Storage) | 10 to 60 Hz, 0.5 g max |
| Vibration (Transportation) | 10 to 60 Hz, 1.0 g max |
| Mechanical Shock (Operating/Storage) | 5 g max, 30 ms max duration |
| Mechanical Shock (Transportation) | 20 g max, 30 ms max duration |
Chassis Mounting: Insert the module into two adjacent chassis slot positions in a compatible Series-A chassis (4, 7, 10, 13, or 17-slot chassis). Ensure total backplane power limits are maintained.
Cabinet Clearance: Maintain a minimum vertical distance of 15.2 cm (6.0 in) and horizontal distance of 10.2 cm (4.0 in) between chassis and enclosure walls for heat dissipation.
Removal and Insertion Under Power (RIUP): Permitted only when installed in ordinary, non-hazardous locations. RIUP is strictly prohibited in Class I, Division 2 hazardous locations without a hot work permit.
Environmental Protection: Enclose the assembly within a NEMA 4 or NEMA 12 panel when required by local codes or operational standards.
UL: UL 508 Industrial Control Equipment Listed
CSA: Class I, Division 2, Groups A, B, C & D Hazardous and Ordinary Locations
FM: Approved for Class I, Division 2 Hazardous Locations
CE Mark: Complies with EMC Directive 89/336/EEC, EN 50081-2 (Emissions), and EN 50082-2 (Immunity)
C-Tick: Meets Australian Radiocommunications Act 1992 Section 182 EMC requirements
Global Express Shipping
Returns & Warranty
Manufacturer: Honeywell
Product No.: TK-PRR021 51309288-475
Country of origin:United States
Product Type: Redundancy Control Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 450g
Dimensions: 145 mm x 137 mm x 50 mm (D x H x W)
