Description

The EVS9325-ES is a reliable servo inverter from the Lenze 9300-Series, engineered for precise motor control in industrial automation. Providing a rated power output of 5.5 kW, this controller is designed to manage motion tasks with high efficiency and precision. With an IP20 protection rating, it is optimized for cabinet-integrated installations. This unit is well-suited for production leaders looking for dependable motion control solutions within established industrial architectures.

Features

• High-Performance Servo Control: Part of the established 9300-Series, known for advanced motion control algorithms.
• Rated Power: 5.5 kW capacity for demanding production line applications.
• IP20 Protection: Suitable for mounting in protected control cabinet environments.
• Precision Engineering: Designed for high-accuracy speed, torque, and position regulation.
• Reliable Integration: Proven performance in diverse manufacturing environments.

Technical Specifications

Installation Guidelines

• Mounting: Ensure vertical mounting within the control cabinet to facilitate proper convective cooling through the integrated heat sink.
• Airflow Clearance: Maintain the manufacturer's recommended clearances above and below the drive to prevent overheating during high-duty cycles.
• Environmental Considerations: Protect the drive from aggressive gases, high humidity, and conductive dust to ensure long-term stability.
• Wiring: Utilize shielded cabling for motor and feedback connections to minimize electromagnetic interference (EMI) and ensure signal integrity.
• Grounding: A robust connection to the cabinet's protective earth (PE) is required to ensure both operator safety and electromagnetic compatibility.
