EVS9328-EK

Lenze

Lenze 9300-Series EVS9328-EK Servo Cam Profiler

SKU EVS9328-EK

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Lenze
  • Product No.: EVS9328-EK
  • Origin Germany
  • Product Type: Servo drives
  • Barcode: 85044095
  • Payment: T/T, Western Union
  • Weight: 12.5 kg
  • Dimensions: 35,00cm x 25,00cm x 25,00cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Lenze 9300-Series Servo drives
Quantità
Call sales Contact

Product Description

Description

The EVS9328-EK is a robust, high-capacity servo cam profiler from the Lenze 9300-Series. Engineered for heavy-duty industrial applications, this unit provides a substantial rated power of 22.0 kW, making it an essential component for high-torque and high-speed motion control systems. Despite its phase-out status (designated in 2017), it continues to be a trusted solution for operational infrastructures requiring precise synchronization and reliable performance in protected, cabinet-mounted environments (IP20).

Features

  • High-Power Motion Control: Rated for 22.0 kW to handle demanding industrial loads.
  • Servo Cam Profiler: Facilitates advanced electronic synchronization and complex motion profiling.
  • Industrial Reliability: Built to the high standards of the 9300-series, ensuring longevity and consistent performance.
  • Cabinet-Ready: Compact design optimized for efficient space usage within industrial enclosures.

Technical Specifications

Feature Specification
Manufacturer Lenze
Range 9300-Series
Product Type Servo Cam Profiler
Rated Power 22.0 kW
Protection Rating IP20
Dimensions 35.00 x 25.00 x 25.00 cm
Weight 12.50 kg
Product Phase Phase-Out

Installation Guidelines

  • Mounting: Due to the 22 kW power capacity, ensure the unit is mounted vertically with generous clearance above and below to allow the cooling fans to operate efficiently.
  • Thermal Management: Because this drive generates significant heat, the control cabinet must feature forced-air ventilation or air conditioning to prevent thermal derating.
  • Wiring: Use shielded motor cables and ensure high-frequency grounding to the cabinet backplane to comply with EMC requirements.
  • Safety: Before performing maintenance, confirm the drive's DC bus is fully discharged. Due to the high power of this unit, strictly follow your facility’s Lock-Out/Tag-Out (LOTO) procedures.
  • Legacy Considerations: Since this unit has been phased out, ensure you have access to appropriate diagnostic cables and legacy software (e.g., Global Drive Control) for configuration and troubleshooting.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the rated power of the EVS9328-EK?
The rated power is 22.0 kW.
When was this model designated for phase-out?
The EVS9328-EK has been designated for phase-out since 2017.
What is the primary function of this drive?
It acts as a servo cam profiler, designed for high-precision electronic motion synchronization.
What is the degree of protection for this device?
It is rated with an IP20 degree of protection.
