Lenze ECS ECSEM016C4B Axis Module Servo Drive

SKU ECSEM016C4B

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Lenze
Product No.: ECSEM016C4B
Origin Germany
Product Type: AC drives
Barcode: 85044090
Payment: T/T, Western Union
Weight: 5.44 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ECSEM016C4B is a high-performance axis module from the Lenze ECS Servo System family. This unit is designed to function as part of a modular multi-axis servo system, converting DC bus voltage (565/675 VDC) into precise AC output (0-400/480 VAC) to drive motors with high accuracy. While this module is now classified as Obsolete, it remains a critical component for the maintenance and repair of established industrial motion control architectures.

Features

Modular Servo System: Specifically engineered as an axis module for scalable multi-axis applications.
Versatile Power Conversion: Accepts 565/675 VDC input and provides 0–400/480 VAC output.
Dynamic Performance: Rated for 16 A overload capacity, suitable for high-acceleration and high-torque production cycles.
Broad Frequency Range: Output frequency capability from 0 to 600 Hz.
Robust Industrial Design: Built to withstand the rigors of automated production environments.

Technical Specifications

Feature	Specification
Manufacturer	Lenze
Range	ECS
Product Type	AC Drive / Axis Module
Input Voltage (DC)	565 / 675 VDC
Output Voltage (AC)	0–400 / 480 VAC
Rated Current (Out)	8 / 6.4 A
Overload Capacity	16 A
Frequency Range	0–600 Hz
Weight	5.44 kg
Product Phase	Obsolete

Installation Guidelines

Integration: This module must be integrated into a larger ECS multi-axis system configuration. Ensure the DC bus connection and EtherCAT/communication cables are properly secured.
Cooling: Because this is a high-power axis module, ensure sufficient airflow within the control cabinet. Keep the cooling fins free of dust and debris to prevent thermal shutdowns.
Safety: Given the high DC bus voltages (up to 675 VDC), ensure that the system is fully discharged before performing any maintenance or wiring tasks. Always verify the DC bus status using a certified multimeter.
Grounding: To ensure EMI compatibility, maintain a clean, low-impedance ground connection to the cabinet backplane.
Legacy Support: As this is an obsolete component, ensure that firmware compatibility with your existing supply module and controller is verified before replacement.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary role of the ECSEM016C4B?

It serves as an axis module within the Lenze ECS multi-axis servo system.

What are the input and output voltage requirements?

It accepts a DC bus input of 565/675 VDC and provides an AC output of 0–400/480 VAC.

What is the product status of this module?

The ECSEM016C4B is currently classified as Obsolete.

What is the overload capacity of this drive?

The drive features a 16 A overload capacity.
