Description

Designed for mechanical and electrical integration within modular drive systems, the Lenze E94AZPS0074 serves as a dedicated installation backplane for Single Drive Size 2 controllers. This backplane simplifies control cabinet assembly by providing a secure mounting foundation and reliable interface connections for the Lenze 9400 HighLine servo drive series. Engineered for configurations that do not require an integrated brake module, it ensures streamlined wiring, robust mechanical stability, and efficient heat dissipation within the enclosure.

Features

• Engineered specifically for Lenze 9400-series Single Drive Size 2 modules.
• Designed for configurations without an integrated brake module.
• Simplifies cabinet installation and reduces wiring complexity.
• Enables rapid module replacement for minimized system downtime.
• Robust mechanical construction suitable for demanding industrial environments.

Applications

• Industrial motion control and servo drive systems.
• Automated packaging and processing machinery.
• Material handling and conveyor systems.
• Textile manufacturing equipment.

Technical Specifications

Installation Guidelines

• Mount the backplane vertically on a flat, conductive, and grounded mounting plate inside the control cabinet to ensure proper electromagnetic compatibility (EMC).
• Ensure all mounting screws are tightened to the manufacturer's specified torque to maintain mechanical integrity.
• Verify that the drive controller size matches the backplane size (Size 2) before attempting insertion.
• Maintain recommended clearance distances above and below the unit to facilitate adequate convective airflow and cooling.
