Lenze EMF2102IB-V003 8200-series Interface Module

SKU EMF2102IB-V003

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Lenze
Product No.: EMF2102IB-V003
Origin Germany
Product Type: Interface Modules
Barcode: 85044095
Payment: T/T, Western Union
Weight: 0.1 kg
Dimensions: 5.10 cm x 10.20 cm x 10.20 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for seamless integration with Lenze 8200-series frequency inverters, the EMF2102IB-V003 communication module establishes reliable serial interfaces in industrial automation systems. This interface module enables flexible point-to-point or multi-point data transmission, supporting both RS232 and RS485 communication protocols. Operating on a standard 24 VDC power supply, it facilitates direct integration into existing control cabinets and distributed drive architectures, ensuring robust data exchange for commissioning, parameterization, and system diagnostics.

Features

Dual-protocol support accommodating both RS232 and RS485 serial communication standards.
Direct plug-in compatibility with Lenze 8200-series drive systems.
Compact form factor designed for space-saving installation within control panels.
Reliable 24 VDC power input configuration.
Robust construction engineered to withstand demanding industrial environments.

Applications

Industrial drive communication networks and distributed control systems.
Parameterization, monitoring, and diagnostics of Lenze 8200-series frequency inverters.
Integration of legacy drive systems into PLC or SCADA architectures via serial links.

Technical Specifications

Manufacturer	Lenze
Part Number/Model	EMF2102IB-V003
Series	8200-series
Product Type	Interface Module
Communication Interfaces	RS232, RS485
Supply Voltage	24 VDC
Dimensions (W x H x D)	5.10 cm x 10.20 cm x 10.20 cm
Weight	0.10 kg
Country of Origin	Germany
Commodity Code	85044095
Lifecycle Status	Phase-Out / Legacy Spare Part

Installation Guidelines

Ensure the host frequency inverter is completely powered down and discharged before inserting or removing the interface module.
Mount the module securely into the designated slot on the front of the Lenze 8200-series inverter, ensuring all connector pins align correctly.
Use high-quality shielded cabling for RS232 and RS485 connections to minimize electromagnetic interference (EMI).
Adhere to standard industrial grounding practices to protect serial communication lines from transient voltage spikes.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What communication protocols does the Lenze EMF2102IB-V003 support?

The EMF2102IB-V003 interface module supports both RS232 and RS485 serial communication protocols.

Which drive series is this interface module compatible with?

This module is designed specifically for compatibility with the Lenze 8200-series frequency inverters.

What is the operating voltage for the EMF2102IB-V003?

The module operates on a standard 24 VDC power supply.

Is the EMF2102IB-V003 currently in active production?

No, the EMF2102IB-V003 is classified as a phase-out/legacy product, making it primarily available as a high-quality spare part for existing installations.
